| Serial Number | Project | Parameters |
| 1 | Processed Hole Diameter | Φ50 - Φ630mm (options available outside this range) |
| 2 | Spindle Drive | High and low-speed transmission + CVT |
| 3 | Spindle Speed | 10-350RPM |
| 4 | Stroke Method | Servo Motor |
| 5 | Stroke speed | 40m/min |
| 6 | Stroke Length | 5000m m |
| 7 | Feeding Method | Servo Motor + Customized Screw |
| 8 | Feeding resolution | 1um |
| 9 | Cooling System | 100 flow/min, Capacity ≥ 500L |
| 10 | Standard fixture holds outer diameter | 60-680mm |
| 11 | Dimensions | 12724mm* 940mm*1700mm |
| 12 | Machine tool weight | 5.8 tons |
