I. Equipment Specifications
| Serial Number | Project | Name | Parameters |
| 1 | Structural form | Axle Head Count: | 2-axis |
| Workstation: | 2 Workstations | ||
| Workbench Surface Size: | 1250*900 | ||
| Workbench Capacity: | 500kg . | ||
| 2 | Spindle Mechanism | Control Method: | Variable frequency motor + synchronous belt |
| Spindle Motor: | 2.2KW | ||
| Processing Hole Diameter Range: | Φ2-Φ60mm (optional in other sizes) | ||
| Transmission Range: | 50-3000 rpm (Continuous variable speed) | ||
| 3 | Stroke mechanism | Control Method: | Servo Motor + Ball Screw |
| Stroke Speed MAX: | 40m/min | ||
| Stroke Length MAX: | 350mm | ||
| 4 | Feeding Mechanism | Control Method: | Servo Motor + Ball Screw |
| Feeding Type: | Constant Feed Rate | ||
| Feeding Resolution: | 0.1um | ||
| 5 | Other | Equipment Weight: | Approximately 4.0 tons |
| Equipment dimensions (Length x Width x Height): | 1500*1500*2350 | ||
| Noise Standards: | Under standard factory conditions, less than 75 decibels under continuous peak loading | ||
| Power Supply: | Three-phase AC: 380V 50Hz | ||
| Environmental Conditions: | Temperature -10~+45°C Temperature < 72% |
Section II: Equipment Processing Precision
Circularity: ≤1um
2. Cylindericity: ≤2um/100mm
3. Roughness: ≤Ra0.1μm.
Section 3: Key Equipment Descriptions
All machine tool base components are made of high-quality cast iron with high strength and undergo overall stress relief treatment.
2. Advanced touch screen control panel, simple and convenient to adjust settings, enabling operators to handle machine tools more intuitively.
3. Equipped with a Siemens control system, it ensures excellent shape accuracy, wire angle, surface roughness, and dimensional consistency through precise control.
4. The machine tool is equipped with a comprehensive cooling and filtration system, mainly composed of "magnetic separator + belt filter + oil cooler", with a filtration accuracy of ≤20um.
5. The machine tool is equipped with a centralized automatic lubrication system, providing a continuous supply of lubricant to all functional components.
