Performance Features
1. Rapid cooling, reaching your desired temperature even faster.
2. Temperature numeric setting with high-brightness LED display.
3. Full-closed magnetic stirrer, maintaining stirring stability.
4. The diameter of the adjustable expansion cover can be adjusted according to the outer diameter of the reaction vessel used, reducing refrigerant consumption. Standardly equipped with a clear glass cover, an optional ring cover is also available.
5. Equipped with an internal secondary stirrer, working in conjunction with the stirrer inside the reaction vessel, to maintain a uniform temperature of the sample.
6. Equipped with a fixed rod, bracket, and beaker clip for easy placement and fixation of titration tubes, sensors, and other accessories (optional). The default sensor is an integrated probe, but an external probe can also be set according to customer requirements.
7. Utilizes imported compressors for high reliability and efficiency.
8. A convenient liquid outlet for staff to change the bath liquid.
Technical Specifications
Model | LYSY-221-40 | ||
Volume of storage tank(L) | 4 | ||
No-load low temperature(℃) | -40 | ||
Work Please provide the Chinese content to be translated. Line piece | Temperature Range within Product Groove(℃) | -40～99.9 | |
Ambient Temperature (℃) | ≤25 | ||
Relative Humidity(％) | ≤60 | ||
Power Supply | 220V±10％ 50Hz | ||
Main To Sex Available Please provide the Chinese content to be translated. Part Piece | Temperature Control | Display Method | LED Digital Display (LCD screen optional) |
Temperature Control Accuracy(℃) | ±0.5 | ||
Sensor | Pt100 | ||
Instrument adjustment range(℃) | -40～99.9 | ||
Set-up Method | At any temperature setting within the operating rangeResolution: 0.1℃ | ||
Safety Protection | Overload, Delay, Overcurrent, Overheat | ||
Cooling CapacityW） | 100-1149 | ||
Cooling unit | Power(W) | 1660 | |
Current(A) | 5.4 | ||
Refrigerant | R404A | ||
Heating PowerW） | 1000 | ||
Blending PowerW） | 30 | ||
Recirculating pump | Power(W) | - | |
Traffic(L/min) | - | ||
Head pump discharge(m) | - | ||
Outer circulation interface(mm) | - | ||
Storage tank | Internal Diameter & Height(mm) | Ф220×130 | |
Material | 304 Stainless Steel | ||
Large Erlenmeyer Flask Capacity (mL） | 2000 (Self-Assembled) | ||
Rotational Speedr/min | 100-1500 | ||
Overall dimensions(mm) | 465×406×450 | ||
Overall Weight(kg) | 40 | ||
Pole | 1 pc (optional) | ||
Technical Documents | 1 Set Includes 1 fuse element | ||
UtilizeLYSY-221-4 Constant Temperature Stirring Reaction Bath - Please read the precautions carefully before use.
Room temperature and humidity
This instrument operates within a normal working temperature range.≤25°C, humidity range of ≤60%, exceeding this range will affect the safety and performance of this instrument.
★ Portable Instrument
Do not handle or tilt the instrument at will after filling the liquid tank to prevent the working medium from entering the mechanism, which could cause danger or damage to the components.
★ Dustproof Ventilation
The area around the instrument with ventilation holes should have sufficient space and be well-protected against dust. Keep the instrument away from heating appliances and direct sunlight.
★ Power Supply
Power VoltageAC220V, 50Hz, with a good grounding system and equipped with a standard three-prong safety plug.
Power VoltageAC380V, 50Hz, control voltage 220V, 50Hz, power plug with three live wires, one neutral wire, with phase sequence protector inside.
★ Wire Protection
Handle the plug with your hands when plugging and unplugging the power source. Absolutely no pulling or tugging on the wires. Strictly prevent damage to the wires from high temperatures.
Medium
Mandatory: Use clean water or other mediums, strictly prevent silt and other foreign matter from entering the cooling system or circulating pump.
★ Replace Fuse
If you suspect the fuse is blown, first unplug the power cord, then replace it with a fuse of the same rating.
Do not use fuses that do not meet specifications.
★ Repair
Do not attempt to disassemble or repair this instrument yourself. The internal components are not designed for self-repair by the average user, except for replacing fuses and cleaning the condenser. In case of a malfunction, the repair should be carried out by a qualified technician.
★ Clean
Before cleaning, disconnect the power supply from the outlet. Wipe the panel and other parts of the machine with a soft, dry cloth. To remove dirt, use a soft cloth dipped in detergent powder or dish soap, then dry with a dry cloth. Be careful to prevent water from entering the mechanism or switches, outlets, etc.
★ Tip
This instrument is not to be used in flammable, explosive, or severely corrosive environments.
