Product Specifications
Model: BCF-40D
Brand: Yingten
Dehumidification Rate (30℃ RH 90%): 40 kg/h
Power: 380V/50Hz
Input Power: 16,500W
Defrosting Method: Automatic Defrost
Recirculating Airflow: 8700 m³/h
Drainage Method: Hose Drainage
Airflow Method: Front Supply, Rear Intake
Operating Environment Temperature: 5-38℃
Weight: 330 kg
Dimensions: Length 1600mm, Width 1500mm, Height 780mm
Ex db IIB T4 Ga/Ex db IIB C T4 Ga
Manufacturer: Henan Tongteng Explosion Proof Electrical Appliances Co., Ltd.
Note:
1. The above technical specifications are for reference only; any changes will not be notified, and the physical unit shall prevail!
2. Customizable - Optional R485 remote control interface; customizable upon request.
The Yiting series explosion-proof dehumidifiers comply with the following standards:
GB3836.1-2021 *1 Part: General Requirements for Electrical Equipment for Explosive Gas Atmospheres
GB3836.2-2021 Part 2: Electrical Equipment for Explosive Gas Atmospheres*2 - Type "d" Flameproof Enclosures
GB3836.4-2021 *2nd Part: Intrinsically Safe "i" Electrical Equipment for Explosive Gas Atmospheres
GB3836.9-2021 *9 Part: Encapsulation Type "m" Electrical Equipment for Explosive Gas Atmospheres
GB 3836.15-2017 Electrical Equipment for Explosive Gas Atmospheres - Part 15: Electrical Installations in Hazardous Areas (Excluding Mines) *JB/T 10538-2005 Explosion-Proof Dehumidifiers and Air Conditioners
The YingTeng explosion-proof dehumidifier operates normally under the following environmental conditions:
a) Altitude not exceeding 2,000m.
b) Suitable for environments with temperatures ranging from 5°C to 38°C, free of corrosive gases.
c) IA, IIB, IIC classifications; explosive hazard areas formed by mixtures of flammable gases, vapors, and air from T1 to T4 groups.
The "YingTeng" explosion-proof dehumidifier series has been specially processed with explosion-proof technology, making it suitable for use in flammable and explosive areas in Zones 1 and 2. It is widely applicable in scientific research, oil, chemical, pharmaceutical, and power plant environments where IIA, IIB class T1 to T4 combustible gases, steam, and air mixtures may form explosive hazards. YingTeng explosion-proof dehumidifiers are suitable for areas with temperature requirements. They have passed inspections by the National Supervision and Inspection Center for Explosion-Proof Electrical Product Quality and have been issued with explosion-proof certificates and CCC explosion-proof certificates. They feature an aesthetically pleasing design, reasonable structure, and easy installation and maintenance. The full series of explosion-proof dehumidifiers are equipped with brand-name compressors, microcomputer intelligent control, digital display, low noise, stable performance, simple operation, and safety, making them highly favored in the market. (Customizable options include: portable explosion-proof dehumidifiers, pipeline explosion-proof dehumidifiers, suspended explosion-proof dehumidifiers, temperature control explosion-proof dehumidifiers, cooling explosion-proof dehumidifiers, low-temperature explosion-proof dehumidifiers, high-temperature explosion-proof dehumidifiers, corrosion-resistant explosion-proof dehumidifiers, etc.).
YingTeng Explosion-proof Dehumidifier Features
LCD Display: Equipped with a sleek and stylish LCD display;
Compressors: Utilize renowned brand compressors, featuring low noise and reliable operation.
Automatic Defrosting: Compressor with 3-minute delay protection, automatic defrost
Safety: Utilizes low-voltage control for enhanced safety.
Mobility: Equipped with swivel casters at the base for easy movement.
Drainage Method: Continuous drainage through hose.
Energy-saving, time-saving, and high-efficiency energy conservation
Control Method: Microcomputer full automatic control, timed on/off.
Humidity can be set as required, automatically shuts down upon reaching the required level, and starts dehumidification when exceeding it.
Strong dehumidification, essential for large warehouses, large workshops, underground garages, and similar locations.
