Product Specifications
Model: BCF-7D
Brand: YingTeng
Dehumidification Rate (30℃ RH 80%): 7 kg/h
Power: 220/V380V/50Hz
Input Power: 2820W
Defrosting Method: Automatic Defrost
Recirculating Airflow: 2000 m³/h
Drainage Method: Hose Drainage
Airflow Method: Front Supply, Rear Intake
Operating Temperature: 5-38℃
Weight: 85 kg
Dimensions: Length 1100mm, Width 700mm, Height 700mm
Explosion-proof marking: Ex db ib mb ll BT 4 Gb / Ex db ib mb ll CT 4 Gb
Manufacturer: Henan Tongteng Explosion Proof Electrical Equipment Co., Ltd.
Note:
1. The above technical specifications are for reference only; any changes will not be notified, and the physical unit is to be taken as the standard!
2. Customizable - with optional R485 remote control interface; customizable as required.
The YingTeng explosion-proof dehumidifier product series complies with the following standards:
GB3836.1-2021 Part 1: General Requirements for Electrical Equipment for Explosive Gas Atmospheres *1
GB3836.2-2021, Part 2: Explosion-proof electrical equipment for explosive gas atmospheres - Type "d" *2
GB3836.4-2021 *2nd Part: Intrinsically Safe "i" Electrical Equipment for Explosive Gas Atmospheres
GB3836.9-2021 *9 Part: Encapsulation Type “m” Electrical Equipment for Explosive Gas Atmospheres
GB3836.15-2017 Electrical Equipment for Explosive Gas Atmospheres*Part 15: Electrical Installations in Hazardous Areas (Excluding Coal Mines) JB/T10538-2005 Explosion-Proof Dehumidifiers and Air Conditioners
The Yinteng explosion-proof dehumidifier operates normally under the following environmental conditions:
a) Altitude not exceeding 2,000m.
b) Suitable for environments with temperatures ranging from 5°C to 38°C, free of corrosive gases.
c) IA, IIB, IIC classifications; explosive hazardous areas formed by mixtures of flammable gases, vapors, and air in T1 to T4 groups.
The "Yingteng" explosion-proof dehumidifier series models have been processed with special explosion-proof technology and are suitable for widespread use in flammable and explosive areas in Zones 1 and 2. They are ideal for research, oil, chemical, pharmaceutical, and power plant environments where there is or may be IIa, Iib Group T1-T4 flammable gases, steam, and air mixtures that pose explosion risks. Yingteng explosion-proof dehumidifiers are suitable for locations with specific temperature requirements. They have passed inspections by the National Explosion-Proof Electrical Product Quality Supervision and Inspection Center and have been awarded explosion-proof certification and explosion-proof CCC certificates. These dehumidifiers feature attractive designs, reasonable engineering, and easy installation and maintenance. The full series utilizes brand-name compressors, microcomputer intelligent control, digital display, and boasts low noise, stable performance, simple operation, and reliability, making them highly favored in the market. (Customizable options include: portable explosion-proof dehumidifiers, pipeline explosion-proof dehumidifiers, hoisting explosion-proof dehumidifiers, temperature-regulating explosion-proof dehumidifiers, cooling explosion-proof dehumidifiers, low-temperature explosion-proof dehumidifiers, high-temperature explosion-proof dehumidifiers, corrosion-resistant explosion-proof dehumidifiers, etc.).
Inten Explosion-proof Dehumidifier Features
LCD Display: Features a sleek and stylish LCD display.
Compressor: Utilizes branded compressor with low noise and reliable operation.
Automatic Defrost: Compressor 3-minute delay protection, automatic defrost
Safety: Low-voltage control for safer use
Mobile Method: Equipped with swivel casters at the base for easy movement.
Drainage Method: Continuous drainage through hose
Energy-saving, time-saving, and highly efficient energy conservation
Control Method: Microcomputer Full-Automatic Control, Timer On/Off.
Humidity can be set as required, automatically shuts down upon meeting requirements, and activates dehumidification if exceeded.
Highly effective dehumidification, essential for large warehouses, large workshops, and underground parking garages.
