Aggregate batching measurement

• The grit hopper is equipped with a grate screen to filter out oversized materials.

• The outer side of the hopper is equipped with a vibration motor, which assists in discharging the material through the vibrating hopper walls, ensuring smooth and efficient operation.

• The belt scale uses variable frequency speed control to ensure aggregate flow. Belt tension and neutralization are adjustable for smooth operation.

• Skirted belt design, minimizes aggregate spillage.Aggregate measurement accuracy: ±2%.

• For materials with high viscosity and prone to bridging, an optional deflector device is available for effective stripping.

2. Aggregate Conveyance

• Electric roller, high load-bearing capacity.Smooth operation, low noise, long service life。

• Channel steel frame, robust and stable, with a long service life.

• Prevent misalignment with dual protection: tail spiral tensioning device, adjustable belt tension at any time; central alignment idler unit,Self-aligning.

• Scrapers are installed at both ends to effectively clean material from the belt surface.

3. Measurement System

• Cement Dosage

Variable Frequency Spiral Weighing, Pollution-Free, Waste-Free, High EfficiencyEco-friendly, cement measurement accuracy: ±1%.

• Water meter

Manual variable frequency speed regulation for metering, easy and quick operation.

Optional with turbine flow meter, electricRegulation, with smaller error: ±1%.

4. Dust Extraction System

• Cement silos are available with pulse jet bag dust collectors or filter core dust collectors, offering high dust removal efficiency and low maintenance costs in the long run.

5. Mixing System

• Compared to traditional lined mixer blades, Betong Heavy Industry's mixing drum employs a double horizontal-axis continuous mixer without lining technology. It boasts strong adaptability, compact size, high yield, and efficient, stable operation.

• Insertable mixing arm, easy to maintain.

• Dual motor drive, low noise, low failure rate, smooth operation.

• Mixes various types and specifications of materials, capable of preparing a wide range of stable soil blends.

• The mixing pot body is焊接 with fully automatic robotic technology, ensuring quality and long service life.

6. Control System

• The electrical control system allows for automatic, semi-automatic, and manual control. It features functions such as formula input and storage, automatic correction of splashing errors, parameter adjustment, weighing calibration, automatic fault diagnosis, automatic alarm, and real-time printing.

7. Installation After-Sales Support (No need to point to a specific location in the image; just allocate a space in the text area to write it)

• Modular design for easy installation, maintenance, and quick relocation and transportation.

WCZ Series Stabilized Soil Mixing Plant Technical Parameters (Four Hopper, Single Bin):

Mobile Site Technical Specifications:
