Aggregate batching measurement

• The grit bin is equipped with a grate screen to filter out oversized materials.

• The outer side of the hopper is equipped with a vibration motor, which assists in discharging the material through the vibrating hopper walls, ensuring smooth and efficient operation.

• The belt scale features variable frequency speed control to ensure aggregate flow. The belt tension and neutral alignment are adjustable, ensuring smooth operation.

• Skirt belt design to minimize aggregate spillage.Aggregate measurement accuracy: ±2%.

• For materials with high adhesion and prone to caking, an optional de-caking device is available for effective stripping.

2. Aggregate Conveyance

• Electric roller, high load-bearing capacity.Operates smoothly, low noise, long service life。

• Channel steel frame, sturdy and durable, with a long service life.

• Prevent misalignment with dual protection: tail end spiral tensioning device, adjustable belt tension at any time; central alignment idler unit,Auto-aligning.

• Scrapers are installed at both ends to effectively clean material from the belt surface.

3. Measurement System

• Cement Dosage

Variable Frequency Spiral Weighing, pollution-free, waste-free, high efficiencyEnvironmentally friendly, cement measurement accuracy: ±1%.

• Water meter

Manual variable frequency speed control metering, easy and quick operation.

Optional with turbine flowmeter for measurement, electricRegulation, with a smaller error margin: ±1%.

4. Dust Removal System

• Cement silos are available with optional pulse-jet bag dust collectors or filter core dust collectors, offering high dust removal efficiency and low maintenance costs.

5. Mixing System

• Compared to traditional lined mixers, Betong Heavy Industry's mixing drum utilizes a double horizontal shaft continuous mixer with no lining technology, offering strong adaptability, compact size, high yield, and efficient and stable operation.

• Insertable mixing arm, easy to maintain.

• Dual motor drive, low noise, low failure rate, smooth operation.

• Can mix various specifications and types of materials, form a stable soil with various mixing ratios.

• The mixing pot body is焊接 with fully automatic robotic technology, ensuring quality and long service life.

6. Control System

• The electrical control system supports automatic, semi-automatic, and manual control. It features recipe input and storage, automatic correction of splashing errors, parameter adjustment, weighing calibration, automatic fault diagnosis, automatic alarm, and real-time printing capabilities.

7. Installation After-Sales Support (No need to point to a location in the image; just allocate a space in the text area to write it)

• Modular design for easy installation and maintenance, with quick relocation and transportation.

WCZ Series Stable Soil Mixing Station Technical Specifications (Four Hopper Single Bin):

Mobile Site Technical Specifications:
