Aggregate batching measurement

• The aggregate hopper is equipped with a grating screen to filter out oversized materials.

• Vibration motor mounted on the outer side of the hopper, assisted discharge with vibrating hopper walls for smooth and efficient operation.

• The belt scale features variable-frequency speed control to ensure aggregate flow. The belt tension and neutral alignment are adjustable, ensuring smooth operation.

• Skirted belt design, minimizes aggregate spillage.Aggregate measurement accuracy: ±2%.

• For materials with high stickiness and tendency to bridge, an anti-bridge device is optional for efficient stripping.

2. Aggregate Conveyance

• Electric roller, high load-bearing capacity.Operates smoothly, low noise, long service life。

• Channel steel frame, sturdy and stable, with a long service life.

• Prevent misalignment, dual protection: tail spiral tensioning device, adjustable belt tension at any time; central alignment idler assembly.Self-aligning

• Scrapers are installed at both ends to effectively clean material from the belt surface.

3. Measurement System

• Cement measurement

Variable-frequency screw metering, pollution-free, waste-free, efficientEco-friendly, cement measurement accuracy: ±1%.

• Water meter

Manual variable frequency speed regulation for measurement, easy and quick operation.

Optional with turbine flowmeter for measurement, electricRegulation, with even smaller error: ±1%.

4. Dust Removal System

• The cement silo can be optionally equipped with a pulse bag dust collector/filter core dust collector, featuring high dust removal efficiency and low maintenance costs in the long run.

5. Mixing System

• Compared to traditional lined agitator mixers, Betong Heavy Industry's mixing drum utilizes a double horizontal shaft continuous mixer with no lining technology. It boasts superior adaptability, compact size, high output, and efficient, stable operation.

• Insertable mixing arm, easy maintenance.

• Dual motor drive, low noise, low failure rate, and smooth operation.

• Mixable with various specifications and types of materials, capable of preparing stable soil with multiple mixing ratios.

• The mixing pot body is焊接 with full-automatic robotic technology, ensuring quality and long service life.

6. Control System

• The electrical control system supports automatic, semi-automatic, and manual control. It features formula input and storage, automatic correction of splashing errors, parameter adjustment, weighing calibration, automatic fault diagnosis, automatic alarm, and real-time printing functions.

7. Installation After-Sales (No need to point to a specific location in the image; just allocate a space in the text area to write it)

• Modular design for easy installation and maintenance, and quick relocation and transportation.

WCZ Series Stabilized Soil Mixing Plant Technical Parameters (Four Hopper, Single Bin):

Mobile Site Technical Specifications:
