Product Overview:

For large-scale photovoltaic grid-connected power systems, to reduce the connection cables between the photovoltaic string inverter and the grid tie cabinet, and for ease of maintenance and improved reliability, it is generally necessary to add a DC collector device between the photovoltaic grid-tied inverter and the grid tie cabinet. To meet this requirement, Im has specially designed a solution that can be paired with photovoltaic inverter products to form a complete photovoltaic power generation system. Utilizing a collector AC box, users can collect a certain number of grid-tied inverter outputs through a surge protector and circuit breaker, facilitating the connection to the downstream grid tie cabinet.

This product is primarily used in grid connection lines for distributed photovoltaic systems ranging from 100KW to 1MW.
