Shijiazhuang Steel Structure House Design & Construction, Prefabricated Light Steel Villa Manufacturer

Light steel villas are a building system constructed with cold-formed thin-walled steel components as the basic structural framework, structural panels as the structural system, and supplemented with other insulation and decorative materials. They are factory-integrated and assembled on-site. The material consists of light steel studs synthesized from hot-dipped galvanized steel strips through cold rolling technology. With the support and combination of accessories, they provide a reasonable bearing capacity to replace traditional housing.

The lightweight steel building system uses 35kg/㎡ of steel, saving over 20kg of materials compared to traditional construction, and with walls at 18cm thick, it increases the usable indoor space.

The roof of the light steel house is constructed from the inside out as follows: gypsum board, R30 spun glass fiber insulation, light steel framing, OSB (Oriented Strand Board), waterproof membrane, and roof decorative layer. The eaves are of a porous construction, allowing the entire frame to ventilate and breathe. The circulating air not only prevents mold but also serves to insulate and retain heat.

Light steel buildings offer excellent thermal insulation properties, preventing the "cold bridge" phenomenon in walls. Data shows that a composite wall with 10cm of insulation has the same thermal insulation effect as a traditional brick wall 1m thick, achieving a 75% energy-saving effect.

Light-gauge steel villa structures are typically two or three stories. Due to the use of lightweight roofing, the structural load is less than that of other layers, allowing the steel columns to be reduced in cross-section, thereby saving steel. To meet aesthetic requirements, horizontal and vertical supports are generally not permitted in villa residential buildings. Therefore, in most cases, the light-gauge steel villa's structural system uses rigid connections for columns and beams, and hinge connections for sub-beams and the main structure, simplifying the construction process.

The main materials of the light steel villa are prefabricated, which allows for quick on-site construction and labor-saving dry work. A 200-square-meter villa can be completed in approximately 20 days, saving a significant amount of construction costs.

Steel structure houses are suitable for a variety of low-rise buildings, with different grades of houses used in residential and public buildings; for example: new rural construction, private villa residential, resettlement housing, rural extension, office buildings, schools, scenic areas, etc.

Shijiazhuang Xuanli Integrated House Co., Ltd. is a one-stop enterprise specializing in the research and development, design, manufacturing, sales, construction, and after-sales service of prefabricated light steel villa construction.
