Hebei Manufacturer of Lightweight Steel Houses, Custom Assembled Lightweight Steel Structure Villa, Aesthetically Pleasing and Seismic-Resistant

Light steel villa is a type of building constructed primarily with light steel frames, typically assembled from tens of thousands of components. Prefabricated light steel villas, also known as light steel structural residential buildings, are homes primarily constructed using light steel frames as the main material. The main material is cold-rolled light steel with hot-dipped galvanized strips. With calculated support combinations, it has a reasonable bearing capacity and can replace traditional housing.

Structural steel assembly buildings do not use any clay bricks, do not damage arable land, and utilize green building materials with 80% recyclable and reusable; highly industrialized, requiring only simple assembly on-site, employing dry construction methods to save water resources without generating construction waste, and without harming the environment.

The walls of lightweight steel villas are primarily composed of wall frames, wall beams, wall bottom beams, wall supports, wall panels, and connecting components. Generally, the internal cross walls of lightweight steel villas are used as load-bearing walls, with wall columns being C-shaped steel components. The wall thickness is determined by the load they bear, typically ranging from 0.84 to 2 millimeters. The spacing between wall columns is usually 400 to 600 millimeters. This wall structure layout of lightweight steel villas can transfer vertical loads and is easy to arrange.

Due to the use of thermal insulation and soundproofing energy-saving structures and materials, the indoor comfort level is enhanced. The built-in piping and thinner walls increase the usable area of the house (approximately 10% more). Additionally, the strong plasticity of the steel structure allows for complex, diverse, and aesthetically pleasing house designs.

The reasons for the current development of light steel structures can be summarized in several aspects: mature technology, flexible structural systems conducive to construction and commerce, high building economy, and technology that aligns with the trend of environmental protection, energy conservation, and sustainable development. In addition to residential use, this system is also employed in scenic area inns, rural housing, light steel景观houses, and observation gardens, among other locations.

Shijiazhuang Xuanli Integrated House Co., Ltd. is a one-stop manufacturer of assembled light steel villa buildings, encompassing research and development, design, production, sales, construction, and after-sales services.
