DK778063 Swiss Screw Thread Cutting Tool Features:
Utilizing BMXP integrated control software, the system operates on the Windows XP platform, features an embeddable control system, and seamlessly connects with various design software.
Machine tool casting bodies are cast using resin sand casting technology, with two high-temperature annealing treatments to ensure the permanent stability of mechanical accuracy.
With XP's robust network capabilities, data exchange and remote control are achievable.
Precision digital high-frequency power supply, stepped pulse waveform, effectively enhancing cutting efficiency, significantly reducing tungsten wire loss.
Technical Specifications:
Model: DK7780, DK77100, DK77120
Work Table Travel: 800×1000, 1200×1000, 1500×1200
Work Surface Size (mm): 820×1240, 1760×1200, 1980×1500
Carrying Weight (kg): 1500, 2000, 2500
Machine Weight (kg) 5000 6500 7500
Machine dimensions: 2900×2500×2100, 3300×3250×2500, 3300×3250×2500
Cutting Thickness (mm) ax.Workplace: 800, 700, 700
Cutting Taper (mm): Max. taper angle ±3° / 80mm
Machining Precision (μm): ≤0.015【Special travel, multi-head machining, and various wire cutting machines can be customized according to customer requirements】
Computer Programming Control System
