Machine tools are mainly composed of the following major components:
1. Cross servo slider: The XZ model uses a servo motor directly connected to a screw principle, enabling the slider to move programmatically. Both the screw and guide rail are made with Japanese THK components.
2. Spindle Assembly: The spindle is a Taiwan-imported Lo-yi or Taiwan University spindle assembly, featuring high rigidity and strong cutting force.
3. 12-axis servo tool tower
4. MT5 Hydraulic Tailstock
5. The casting bed is made of high-strength HT300 nodular iron cast in resin sand with a rational rib structure, offering excellent rigidity and stability. Additionally, it undergoes annealing and long-term natural aging treatment to significantly reduce residual internal stress, ensuring high precision and long service life for the machine platform.
Equipment Features
1. Machine Tool Structural Features
◇ The bed and base are cast as a single unit with a hydraulic tailstock inclined bed design. Utilizing whole molding with cast iron resin sand, it features a tight ribbed plate structure, offering good rigidity and vibration resistance. The operation is flexible and chip removal is convenient. Suitable for long shaft workpieces, heavy loads, high precision, high rigidity, and high-gloss surface finishing requirements.
Tailstock hydraulic control, automatic pin extension/retraction, rigid and stable, can be controlled with foot switches.
◇ The hydraulic rotating turret design features a 12-position hydraulic servo rotating turret, offering high positioning accuracy, low failure rate, quick tool change, and nearby tool change. It is suitable for heavy loads, continuous cutting, and rapid machining, maintaining long-lasting high precision and excellent surface finish. Ideal for complex workpieces, high precision, high rigidity, and high-gloss surface finishing requirements.
◇ The spindle is equipped with imported precision bearings, featuring a labyrinth-style waterproof design and a finned spindle box design for dust and water resistance. Utilizing high-tech lubrication technology and a unique sleeve structure spindle ensures stability, guaranteeing axial rigidity, radial rigidity, and machining accuracy. The spindle servo motor solution is adopted to achieve wide-range automatic stepless speed control.
◇ High-precision, high-speed, and high-rigidity ball screw, linear guide rail X-axis, Z-axis, matched with Taiwan original imported ball screw and linear guide rail. Large span between tracks, X/Z displacement speed up to 24M/min, enhancing machining efficiency. The rotation of both axes is directly connected by a servo motor and precise ball screw through an elastic coupling, with good load-bearing and high positioning accuracy. Equipped with a computerized automatic lubrication system for forced lubrication. Ensures long-term stability of machine tools.
The hydraulic station is equipped with renowned variable pumps, motors, solenoid valves, and an additional air-cooling unit, ensuring low noise and oil temperature.
The electrical control box is equipped with a heat exchanger, which quickly expels the heat inside the box, maintaining a constant temperature within and ensuring stable operation of the control system.
◇ Efficient lubrication with long service life and no maintenance required; lead screw and guide rail units are equipped with an automatic centralized lubrication system using light oil, ensuring thorough and reliable lubrication. The machine tool is fitted with an automatic lubrication device that features oil deficiency and fault alarm functions.
LED lighting: energy-saving, efficient, and long-lasting; three-color operational status indicator lights: real-time display of machine tool status for easy on-site visual management.
◇ Attractive full-enclosure protection with excellent waterproofing; high-strength tempered safety glass windows on the moving door and windows; easy and smooth operation of the sliding door; bright working lights; and ergonomic operation height for comfort.
Main Technical Parameters of Machining Machine
Main Configuration and Accessories
