Experimental Training Content

1) CNC System Functionality, Structure, Installation, Parameter Setting, and Tuning

2) CNC Machine Tool Alarm Recognition, Fault Diagnosis, and Repair

3) CNC system data backup, communication with computer

4) Communication Servo Motor Drive Wiring, Tuning, and Dynamic Characteristics

5) Main shaft motor wiring, parameter settings, and tuning

6) Hall elements, proximity switches, and the principles and applications of sensors

7) Experimental Setup and Tuning of Semi-Closed-Loop Control

8) PLC Commands, Programming, and Logical Control

9) Definition, setup, and debugging of input/output interfaces

10) Principles and Applications of CNC Machine Tool Electrical Cabinet Control Circuit

11) Principles, Performance, and Wiring of Low-Voltage Electrical Components

12) Lead screw pitch, transmission ratio, and other parameter settings

13) Reverse Gap Compensation Test

14) Lead Screw Pitch Error Compensation Experiment

15) Programming and Interpolation Motion Experiment for CNC Machining Centers

16) Tuning and programming of the lathe center's C-axis function (all-in-one)

Product Features

Aluminum alloy structure

2) Transparent Display of the Actual Industrial Field Electric Control System

3) PLC Control Panel

4) Scale disk displays servo motor rotation

5) Transparent Protective Cover for Motor Area

6) High-Intensity Convection Fan

7) Rollable and Mobile

8) Complete configuration of training manuals, system instructions, troubleshooting guides, PLC programs, debugging and development software packages, data CDs, and more.
