The CK0638 series CNC lathe is a high-precision, high-reliability CNC lathe with an excellent performance-to-price ratio, co-produced by our company and domestic machine tool manufacturers. It features a novel structure, comprehensive functions, excellent rigidity, and high rotational speed.
The CK0638 can automatically complete processing of inner and outer circles, end faces, steps, slots, tapered surfaces, spherical surfaces, non-spherical surfaces, and threads, making it an ideal production equipment for processing a variety of complex parts in different specifications.
The machine tool comes with programming simulation teaching software, making it an advanced equipment for school CNC teaching and practice, meeting the school's needs for industry, academia, and research.
Key Technical Parameters
Model CK0638
Bed frame large swing diameter 380mm
Deck plate with large turning diameter 200mm
Tip distance 500mm
Spindle Head Model D-5
Main shaft bore taper MT5
Bore diameter of the main shaft 41mm
Speed Range200-3200 rpm (Continuous Variable Transmission)
Pulse Energy 0.001mm
Fast forward speed8000mm/min
刀架 T-slotFour-station electric tool holder (optional six-station holder available)
Main Motor Power4kw, rated speed 1440rpm
Tailstock锥孔 MT4
Processing Park Degree 0.005mm
Roughness finish Ral.6
Positioning Accuracy X:<0.012，Z:<0.020
Repeatability accuracy X:<0.005，Z:<0.007
Power SupplyThree-phase/380V/50Hz, 6KVA
Features and Performance:
1. Entire cast base, rigid, bed body guide rail super-audio quenched, high hardness, thick hardened layer, all resin sand casting
2. Independent spindle structure, supported by imported high-precision rolling bearings, high speed, high precision, and long lifespan
3. Main shaft variable frequency stepless speed control
4. High-precision ball screw drive, elastic coupling direct connection
5. Multi-station automatic indexing turret with high repeat positioning accuracy
6. Manual/Automatic Cooling System
7. Programmable lubrication control system ensures uniform lubrication of guideways, screws, etc.
8. Fully enclosed mobile transparent protective cover, dust-proof, aesthetically pleasing
9. Machine tool precision meets all relevant standards
10. Offer compatible CNC programming and simulation software, with programs directly transmitted to the machine tool via RS232 interface.
Numerical Control System Configuration
Available SystemSiemensFANUCMitsubishiCentral ChinaGuangshuKND Huaxing
808D/828D/840D Oi mate/oi
Optional accessories
Six-position, eight-position electric knife holder
Pneumatic collet, pneumatic door system
Configurable CNC systems to meet customer specifications
