Shanghai Angle Iron Bending Machine Pricing_Angle Iron Bending Machine Cost_Angle Iron Bending Machine for Sale [Hongye Machinery]

Angle iron is used to construct frameworks, such as the towers for high-voltage transmission, the frames on both sides of steel bridge main beams, the columns and booms of tower cranes on construction sites, as well as the columns and beams in workshops. For smaller applications, it can be seen in decorative stands for flower pots along the road during holidays, or in brackets for hanging air conditioners and solar panels under windows.
Angle Iron Bending Machine Technical Specifications:
Dimensions: 2000*1500*1200mm
Weight: 3 tons
Motor Power: 3 kW
Molding Steps: 8
Material thickness: 1.0-3.0mm
Work Speed: 13 meters per minute
Transmission Method: Chain Drive
Roller Material: Precision machined Cr15 followed by heat treatment
Main shaft material: Heat treated 45# steel, precision machined
Spindle Diameter: 70mm
Rack Wall Panel: Steel plate 16mm thick
Rack: Welded from 300H steel
Forming Shearing Molds: Cr12Mvo precision processed and heat treated
Electrical Control System: PLC computer touch screen control circuit
Manual Material Feeding Rack: 3 tons
Warranty period: One year

Our factory is located in the largest wholesale and processing market for door industry materials in China, in Dayuan Town, Fuyang City, Zhejiang Province. We are a professional manufacturer of cold bending forming equipment, mainly producing door frame forming machines, stainless steel arc pressing machines, angle iron forming machines, special-shaped cold bending components, photovoltaic support forming machines, punching and forming production lines, greenhouse support forming machines, edge wrapping forming machines, foam wall panel plug forming machines, and beam support forming machines, among others. Our company is equipped with complete production and processing facilities, boasts a research and development team led by professional engineers and experienced production technicians. Adhering to the principle of "honesty as the way of business and quality as the foundation of survival," we are dedicated to providing excellent service to friends from all walks of life.
