The I-Mill series carding machines feature the following characteristics: A: Small footprint, wide applicability.
The I-Mill series carding machines feature the following characteristics:
A: Compact in size, versatile in application.
B: This series of napped machine is suitable for both woven and knitted fabrics.
C: This series of napped fabric machine is versatile. After a simple modification, replacing the weaving line allows for double-sided napping simultaneously.
| Standard Configuration | Select Configurationnal configuration） |
| High-positioned fabric intake | The number of grinding rolls can be customized within the allowed structural conditions. |
| Two sets of abrasive sanding machine hosts | Abrasive materials available include carbon fiber and ceramic fiber. |
| Swag Drop Cloths | Electrical brands available include SIEMENS, Schneider, and others. |
| Mainframe Integrated Electrical Control Cabinet + Touchscreen | Optional standalone electrical cabinet + split-type touch control box |
| Electrical and mechanical components | Optional Electric Ironing Press |
| Two vacuum systems | Adjustable tension架 available |
| Manual Pressing Fabric | Optional photoelectric alignment |
| Available in large roll sizes |
| Key Technical Parameters (Technical Date:) | |
| Nominal Width | 1600~3200（mm） |
| Installed Power | ≈55~85（KW） |
| Mechanical Speed (Production Speed) | 5~70（m/min） |
| Brush Roll Diameter | ≈Φ215（mm） |
| Air Pressure (Compressed Air Value) | 0.6（Mpa） |
| Machine Weight | ≈6~8（T） |
| Dimensions (Physical Size) | ≈5500x6300X4000（mm） |
