Key Features

The keyboard assembly is composed of special PC/ABS key frames and zinc alloy keys. The product boasts excellent anti-vibration, anti-corrosion, and waterproof properties. Particularly, it can be operated effectively in harsh environments.

2. User-friendly key layout with deeply molded die-cast patterns and characters on the key surface for better operation. The characters and patterns on the key surface can be customized according to customer requirements.

3. The keyboard features a unique enclosed film installation design, offering excellent waterproof and dustproof capabilities.

4. The keyboard PCB board is a double-sided gold-plated board with silicone conductive carbon particles for contact, ensuring reliable connection.

5. Zinc alloy key switches, available in custom paint colors for surface characters and patterns.

6. Key surface electroplating colors: Bright Chrome, Matte, available for customization as per customer's request.

7. Conductive rubber is made from natural silicone rubber, offering wear and corrosion resistance, as well as aging resistance.

8.3" x 4" keyboard design, featuring 10 numeric keys and 2 function keys. The key layout can be redesigned according to customer requirements.

9. Output interfaces include USB, PS/2, RS232, and XH connectors (optional).

10. Easy and convenient embedded installation.

Packaging Details

Outer Carton Dimensions: 42×35×11.5 cm

1 Carton Quantity: 80 PCS

User Selection

Suitable for fuel dispensers, access control systems, elevators, safes, coin-operated machines, combination locks, various telephones, and industrial equipment applications.

After-sales service

In the absence of human damage, our company is responsible for free repairs within 1 year.
