YX95-325 closed rib floor deck enhances the concrete's grip on the deck, achieving true composite action in composite floors. The closed rib floor deck composite floor can reduce the floor thickness and increase the clear height. For open rib floor decks, the board thickness for small panels is required. The bottom of closed rib floor decks is flat, with webbing flush, offering various ceiling treatments for different room functions and needs. Direct painting can create a tongue-and-groove ceiling (similar to aluminum ceiling tiles), while applying putty and painting with water-based coatings can result in a flat ceiling. It can also be decorated with wall fabric or wallpaper to create colorful ceilings or utilize the unique clip slot hanging system for suspended ceilings, meeting the aesthetic needs of owners more economically.
I. Technical Specifications:
YX95-325 Closed Deck Sheet, with a wave height of 95mm and effective width of 325mm, is cold-pressed from galvanized steel plate with excellent load-bearing capacity and fire resistance. Its production process and acceptance procedures are strictly in accordance with the national standard GB/T12755-2008 for Corrugated Steel Sheets.
The materials used are generally sourced from leading domestic steel producers such as Shougang, Handong, Tanggang, Angang, Baogang, and Wugang.High-endCarbon structural steel or low-alloy steelSteel qualityHigh-endSatisfyGB/T2518-2008 National Galvanized Sheet Standard, thickness typically in 0.75mm, 0.8mm, 0.91mm, 1.0mm, 1.2mm, and 1.5mm base sheets, with zinc coating usually on both sides at 60g, 80g, 100g, 120g, 180g, 220g, and 275g.SupremeAvailable600g, yield strengths commonly used include 250MPA, 280MPA, 320MPA, 350MPA, 450MPA, 550MPA, etc.
II. Product Principle:
The deck plate is made by cold bending and forming from galvanized steel sheets. After installation, it is suitable for pouring concrete and, together with the concrete, forms an integrated floor structure. It is the main component in building steel structure engineering, second only to beams and columns, and serves as a long-term support formwork for the floor.
III. Product Performance:
Light in weight, high in strength, excellent stiffness, corrosion resistance, seismic resistance, fire resistance, easy construction, and easy to update, while also meeting the national promotion of energy-saving, environmental protection, and safety requirements.
IV. Product Advantages:
1. Save a substantial amount of temporary templates, eliminating all or part of template support.
2. Used as tension-restrained steel, it reduces the manufacturing and installation work of steel bars.
3. Reduces concrete consumption, mitigates long-term structural loads, suitable for high-rise buildings.
4. Significantly reduces labor in transportation, storage, and installation, minimizing workload.
5. Facilitates the laying of communication, power, heating, and other pipeline systems, as well as the installation of insulation, soundproofing, heat-insulating, and vibration-isolation materials, thereby enhancing the floor performance.
6. Maximize the excellent tensile strength and ductility of steel, as well as the superior compressive strength and greater rigidity of concrete.
Offer a variety of work platforms to achieve three-dimensional operations, accelerate progress, shorten project duration, and reduce overall costs.
8. Robust concrete bond shear (special closed rib design and embedded lugs on the web).
V. Product Applications:
1. High-rise buildings (business centers, luxury hotels, bank buildings, shopping malls, etc.)
2. Multi-story buildings (large supermarkets, schools, villas, 4S car dealerships, etc.)
3. Public Buildings (exhibition centers, sports facilities, opera houses, libraries, passenger stations, airport terminals, etc.)
4. Industrial Buildings (Logistics Centers, Power Plants, Nuclear Power Stations, Factory Buildings, etc.)
