YX65-167-500Closed deck rib angles enhance the grip of concrete on the deck, enabling true composite action in composite slabs. Closed deck composite slabs can reduce slab thickness and increase net height. With open deck slabs, the small plate thickness is required. The flat bottom and flush web of closed deck slabs offer various ceiling treatment options for different room functions and needs. Direct painting can create tongue-and-groove ceilings (similar to aluminum ceiling tiles), applying putty and then water-based paint can make flat ceilings, or directly pasting wall fabric or wallpaper to decorate colorful ceilings. Additionally, the unique card slot hanging system of closed decks can be used to install ceilings, providing a more economical solution to meet the aesthetic requirements of the owner.

I. Technical Specifications:
     YX65-167-500Closed Deck Plate Wave Height95mm in thickness, with an effective width of 325mm, this hot-dipped galvanized steel sheet is cold-pressed, offering strong load-bearing capacity and good fire resistance. Its production process and acceptance procedures are strictly in accordance with the GB/T12755-2008 national requirements for corrugated steel sheets.
The materials used are generally sourced from leading domestic steel producers such as Shougang, Handong, Tanggang, Angang, Baosteel, and Wuhan Iron and Steel.High-endCarbon structural steel or low-alloy steelSteel qualityHigh-endSatisfyGB/T2518-2008 National Galvanized Sheet Standard, with thicknesses typically ranging from 0.75mm, 0.8mm, 0.91mm, 1.0mm, 1.2mm, and 1.5mm base sheets, and zinc coating weights usually at 60g, 80g, 100g, 120g, 180g, 220g, and 275g on both sides.SupremeAvailable600g, commonly used yield strengths include 250MPA, 280MPA, 320MPA, 350MPA, 450MPA, and 550MPA, etc.


II. Product Principle:

This deck plate is made by rolling and cold bending galvanized steel sheets, and is suitable for concrete pouring after installation. It forms an integrated floor structure when combined with concrete, serving as the primary component in building steel structure engineering, second only to beams and columns, and is used as a long-term support formwork for the floor slab.


III. Product Performance:

Lightweight, high strength, excellent stiffness, good corrosion resistance, strong seismic resistance, good fire resistance, easy construction, and easy to update, while meeting the national promotion of energy-saving, environmental protection, and safety requirements.


IV. Product Advantages:

1. Save a substantial amount of temporary templates, eliminating all or part of template support.

2. As tensioned reinforcement, it reduces the manufacturing and installation work of steel bars.

3. Reduces concrete consumption, alleviates long-term structural loads, suitable for high-rise buildings.

4. Saves a significant amount of labor in transportation, storage, and installation, reducing workload.

5. Facilitates the laying of communication, power, heating, and other pipeline systems, and can install insulation, soundproofing, heat-insulating, and vibration-isolation materials to enhance floor performance.

6. Maximize the excellent tensile strength and ductility of steel, along with the superior compressive strength and high rigidity of concrete.

7. Offer various work platforms for comprehensive operations, accelerating progress, shortening project duration, and reducing overall costs.

8. Robust concrete bond shear resistance (with special closed rib pattern and embedded grooves on the web).


V. Product Applications:

1. High-Rise Buildings (Business Centers,星级酒店, Bank Buildings, Shopping Malls, etc.)

2. Multi-story Buildings (large supermarkets, schools, villas, 4S car dealerships, etc.)

3. Public Buildings (convention centers, sports facilities, opera houses, libraries, bus stations, airport terminals, etc.)

4. Industrial Buildings (logistics centers, power plants, nuclear power stations, factories, etc.)
