YX42-215-645Closed-web deck ribs enhance the concrete's grip on the deck, achieving true composite action in composite slabs. Closed-web deck composite slabs can reduce slab thickness and increase net clearance height. For open-web decks, the board thickness is required. The flat bottom and flush web of closed-web decks allow for various ceiling treatments to meet the different functions and needs of various rooms. Direct painting can create a tongue-and-groove ceiling (similar to aluminum ceiling tiles), while applying putty and then water-based paint can result in a flat ceiling. Additionally, wall fabric or wallpaper can be directly applied to create colorful ceilings, or the unique clip-on slot system of closed-web decks can be used for suspended ceilings, all while satisfying the aesthetic needs of the owner more economically.
I. Technical Specifications:
YX42-215-645Closed Deck Plate Wave Height95mm, 325mm effective width hot-dip galvanized steel sheet cold-rolled, with strong load-bearing capacity and good fire resistance. Its production process and acceptance procedures are strictly in accordance with the GB/T12755-2008 national requirements for profiled steel sheets.
Materials typically used are sourced from leading domestic steel producers such as Shougang, Handong, Tanggang, Anshan, Baoshan, Wuhan, etc.High-endCarbon structural steel or low-alloy steelSteel qualityHigh-endSatisfyGB/T2518-2008 National Galvanized Sheet Standard, thickness typically ranges from 0.75mm, 0.8mm, 0.91mm, 1.0mm, 1.2mm, to 1.5mm base sheets, with zinc coating usually available in double-sided options of 60g, 80g, 100g, 120g, 180g, 220g, and 275g.SupremeAvailable600g, yield strengths commonly used include 250MPA, 280MPA, 320MPA, 350MPA, 450MPA, and 550MPA, etc.
II. Product Principle:
This deck plate is formed by cold bending from galvanized steel sheets, suitable for concrete pouring after installation. It works in conjunction with concrete to form an integrated floor structure, serving as the primary structural component in building steel structures, second only to beams and columns, and is used as a long-term supporting formwork for the floor.
III. Product Performance:
Lightweight, high strength, excellent rigidity, good corrosion resistance, strong seismic resistance, good fire resistance, easy installation, easy to upgrade, and in compliance with national promotion of energy-saving, environmental protection, and safety requirements.
Four, Product Advantages:
1. Save a substantial amount of temporary templates, eliminating all or part of template support.
2. As tensioned reinforcement, it reduces the manufacturing and installation work for steel bars.
3. Reduce concrete consumption, alleviate long-term structural loads, suitable for high-rise buildings.
4. Substantially reduces labor requirements in transportation, storage, and installation, minimizing workload.
5. Facilitates the laying of communication, power, heating, and other pipeline systems, as well as the installation of insulation, soundproofing, heat-insulating, and vibration-isolation materials, thereby enhancing the floor performance.
6. Fully utilize the excellent tensile strength and ductility of steel, as well as the superior compressive strength and greater rigidity of concrete.
7. Offer a variety of work platforms to achieve multi-dimensional operations, accelerate progress, shorten project duration, and reduce overall costs.
8. Robust concrete bond and shear resistance (special closed rib pattern and embedded lugs on the web).
V. Product Applications:
1. High-rise buildings (business centers, luxury hotels, bank buildings, shopping malls, etc.)
2. Multi-story Buildings (Large Supermarkets, Schools, Villas, 4S Car Dealerships, etc.)
3. Public Buildings (convention centers, sports venues, opera houses, libraries, bus stations, airport terminals, etc.)
4. Industrial Buildings (Logistics Centers, Power Plants, Nuclear Power Stations, Factory Buildings, etc.)
