Our ZRSO electric O-type cut-off ball valves feature an O-type ball core structure, hence also known as electric switch ball valves. These valves are characterized by their compact design, small size, light weight, close distance between the valve seat and end face flange, minimal material retention, and excellent sealing performance. Suitable for two-way cut-off applications, the valve is directly connected to the actuator, eliminating the need for a servo amplifier. Operation can be controlled with a 220VAC power supply. The electric O-type cut-off ball valves offer simple wiring, compact structure, small size, light weight, low resistance, and stable, reliable operation. They are commonly used in applications with stringent sealing requirements and are widely applied in automatic control systems across industries such as chemicals, petrochemicals, and light industry.
 |  |
|---|
| Electrical O-Type Cut-Off Ball Valve (with OV-TORK Actuator) | Electrical O-Type Cut-Off Ball Valve (with BV-TORK explosion-proof actuator) |
|---|
Electrical O-Type Cut-Off Ball Valve, Main Technical Parameters
| Nominal Bore Diameter (mm) | 15 | 20 | 25 | 32 | 40 | 50 | 65 | 80 | 100 | 125 | 150 | 200 | 250 | 300 |
|---|
| Flow Coefficient Kv | 21 | 38 | 72 | 112 | 170 | 273 | 384 | 512 | 940 | 1452 | 2222 | 3589 | 5128 | 7359 |
| Nominal Pressure (MPa) | PN1.6、2.5、4.0、6.4MPa |
| Leakage Rate | Soft Sealing: Zero Leaks; Hard Sealing: ≤ 10^-5 of rated flow |
| Valve body style | Two-piece valve body (floating ball) | Two-piece valve body (fixed ball) |
| Valve core style | O-ring ball valve core |
| Sealed Packing Material | PTFE (Polytetrafluoroethylene), metal石墨 wrapped gaskets |
| Form of Connection | Flanges, Welding, Threaded |
| Flow characteristics | Approximate quick-opening feature |
| Adjustable Range | DN15-65 | DN80-300 |
| 250:1 | 350:1 |
| Basic Tolerance | ±1% |
| Dead zone | ≤1% |
| Difference Return | ≤1% |
| Applicable Temperature | Sealed face |
| PTFE ≤ 150°C, RTFE ≤ 180°C, PPL ≤ 300°C, Rigid Seal ≤ 450°C |
| Configuration Actuator | Available for series angle positioners such as PSQ, HQ, UNIC, 361RS, JO, etc. |
| Control Method | Toggle switch indicator (dual-position switch), Passive contact signal, 1/5K potentiometer, Intelligent adjustment (4-20mA analog signal control) |
Electric O-Type Cut-Off Ball Valve Actuator Technical Specifications
| Actuator Category | Imported OV-TORK Series Actuator Specifications | Introducing the 3610R series actuator specifications | BV-TORK Series Actuator Specifications |
|---|
| Power Voltage | Standard: 220V AC Single Phase; Optional: 110V AC Single Phase, 380/440V AC Three Phase, 24V/110V/220V AC |
| Output Torque | 50N·M～2000N·M | 50N·M～1500N·M | 50N·M～3000N·M |
| Motion Range | 0～90° 0～360° | 0～90° | 0° to 90°, 0° to 270° available |
| Control Method | Toggle switch indicator (two-position switch control), Passive contact signal, 1/5K potentiometer, Intelligent adjustment (4-20mA analog signal control) |
| Action Time | 15/30/60 seconds | 10/15/30 seconds | 18S～112S |
| Protective Device | Overheat Protection | Overload Protection | Built-in overheat protection, overload protection |
| Ambient temperature | -30°～60° | -30°～60° | -20℃～+70℃ |
| Manual operation | With handle for operation | With handle for operation | Mechanical clutch mechanism, with handwheel operation |
| Mechanical Limit Switch | Electrical and mechanical dual-limiting | Electrical and mechanical double-limiting | 2 external adjustment bolts |
| IP rating | IP65 | IP55 | IP65, IP67, Customizable IP68 |
| Intrinsically Safe Rating | Non-explosive | ExdⅡ BT4 | ExdⅡ BT4,ExdⅡ CT6 |
| Position Measurement | Optional switch or potentiometer | Proportional Control Unit | Potentiometer, Proportional Control Unit |
| Drive Motor | 8W/E | AC reversible motor | Cage-type asynchronous motor |
| Input interface | PE 1/2" Inlet Line Lock | 2-PF 1/2" Input Line Lock | 2 PF 3/4" |
| Shell Material | Aluminum alloy | Steel, Aluminum Alloy | Steel, aluminum alloy, aluminum bronze, polycarbonate |
| Outer coating | Dry powder, epoxy polyester, with strong anticorrosive properties |
| Utilizing superior electric braking circuits, we offer high positioning accuracy, a responsive actuator, quick start and stop, and smooth operation. Additionally, our products feature strong anti-interference, surge voltage resistance, and puncture prevention capabilities. |
| Suitable for frequently operated control circuits; at a 25% duty cycle, the number of operations per hour can reach 630-1200 times. |
Electrical O-type cutting ball valve, main component materials
| Part Name | Material Name |
|---|
| Valve body | WCB | 304(CF8) | 316(CF8M) | 316L(CF3M) |
| Sphere | 2Cr13 + Nitriding treatment | 304 | 316 | 316L |
| Valve Stem | 2Cr13 | 304 | 316 | 316L |
| Seal ring | PTFE (Polytetrafluoroethylene), PPL (Glass-Reinforced PTFE), Para-Phenylene, Flexible Graphite |
| Applicable Medium | Water, gas, steam, oil products, etc. | Corrosive media such as nitric acid | Acetic acid and other corrosive mediums | Urea and other corrosive media |
Electric O-Type Cut-off Ball Valve - Main Performance Specifications
| Test Standard | Nominal Pressure (Mpa) | Pressure Class | JIS(Mpa) |
|---|
| Test Pressure (Mpa) | 1.6 | 2.5 | 4.0 | 6.4 | 10.0 | 150 | 300 | 600 | 10K | 20K |
| Strength Test | 2.4 | 3.8 | 6.0 | 9.6 | 15.0 | 3.1 | 7.8 | 15.3 | 2.4 | 3.8 |
| Seal Test | 1.8 | 2.8 | 4.4 | 7.0 | 11.0 | 2.2 | 5.6 | 11.2 | 1.5 | 2.8 |
| Airtightness Test | 0.5～0.7 |
Electric O-Type Cut-off Ball Valve Product Selection
(1) Valve Body Parameters: Nominal Diameter, Working Pressure, Process Medium, Application, Valve Body Material, and a series of other parameters.
(2) Actuator Parameters: Power Voltage, Control Method, Control Signal (4-20mA, 1-5V), Operating Mode (Electrical-Open, Electrical-Close)
Please provide as detailed technical specifications as possible for our production and technical team to accurately select the right product for you. Should you have any questions, feel free to call us, and we will strive to provide you with excellent service!
