I. Brief Introduction:

Product Name: Spectrum Analyzer

Brand: R&D Technology

Product Model: N9030A

Frequency Range: 3.6, 8.4, 13.6, 26.5, 43, 44, 50 GHz

N9030A-RT1 Real-time spectrum analysis with up to 85 MHz bandwidth, basic detection

Two, Main Features and Functions

Achieve capture probability for signals with a short duration of 15 μs, and provide a full set of advanced triggering functions to capture elusive signals.

Observe signal dynamics across various display modes: digital and sweep density, spectrum, spectral plots, power variations over time, and seamless real-time analysis.

Protect Your Investment – Add Real-Time Spectrum Analysis (RTSA) to Your PXA, at a Fraction of the Solution Cost

Seamlessly integrate the 89600 software into your system, allowing you to analyze complex signals.

External mixer extends RTSA measurement to millimeter wave range

3. Technical Specifications

Frequency3 Hz to 50 GHz, mixer with 1.1 THz

Frequency Options3.6, 8.4, 13.6, 26.5, 43, 44, 50 GHz, up to 1.1 THz with a mixer

Analyze bandwidth160 MHz

Bandwidth Option25 MHz standard, 40, 85, 125, 160 MHz

Real-time bandwidth160 MHz

Real-time Bandwidth Option85, 160 MHz

1 GHz DANL-171 dBm

At 1 GHz, the phase noise at a 10 kHz frequency offset-132 dBc/Hz

At 1 GHz, phase noise at 30 kHz offset-132 dBc/Hz

At 1 GHz, phase noise at 1 MHz offset-146 dBc/Hz

Overall Amplitude Accuracy±0.19 dB

3rd Order Intercept (TOI), 1 GHz+22 dBm

3rd-order dynamic range at 1 GHz119 dB

Instrument TypeSpectrum Analyzer
