Note: The drawings are designed by Hunan Dingchuan Architectural Design Co., Ltd. and have been registered for copyright protection with the National Copyright Administration. The design of the drawings conforms to the national construction industry standards, and the structural safety is subject to the mandatory legal liability of the architectural design industry. If the contractor encounters difficulties understanding the drawings or requires technical support during construction, please call our customer service hotline at 400-8080-889. We will be happy to provide assistance.
| Drawing Attributes | |||
| Item Number: DC1026 | |||
| Room size:12.3 meters | |||
| Drawing content | ||||
| Inclusive of general architectural description, floor plans, elevation views, section views, staircase detail drawings, door and window dimensions, and node details. | ||||
| Basic flat construction drawings, reinforcement details for beams, columns, floors, and large-scale views. | ||||
| Include floor plans for water supply and drainage levels, system diagrams, and detailed drawings, etc. | ||||
| Inclusive of power distribution system diagrams, lighting plans for each floor, outlet layouts, low-voltage layouts, lightning protection and grounding layouts, etc. | ||||
| Design Features | ||||
| Entrance hall, Living room (open space), Bedrooms (with attached bathrooms), Bedroom, Kitchen, Dining room, Bathroom | ||||
| Living room, bedroom (with bathroom), bedroom, study, bathroom, balcony | ||||
| Billiards room, bedroom (with bathroom, wardrobe, balcony), 2 bedrooms, bathroom, balcony | ||||
This set of drawings includes 69 full A3 construction plans + 3 color renderings, includes printing (default is one copy, additional copies will cost an extra 100 RMB per copy), free express shipping, no electronic version available.
