Seamless steel tube specifications: outer diameter x wall thickness

Outer Diameter × Wall Thickness

38×4-5-6-8-10

42×3.5-4-5-6-8-10-12

45×3.5-4-5-6-8-10-12

48×3.5-4-5-6-8-10-12

51×3.5-4-5-6-8-10-12

57×3.5-4-5-6-8-10-12-14

60×3.5-4-5-6-8-10-12-14

63×3.5-4-5-6-8-10-12-14

73×4-5-6-8-10-12-14-16

76×4-5-6-8-10-12-14-16

83×4-5-6-8-10-12-14-16 -18-20

89×4-6-8-10-12-14-16-18-20-22-25

95×4.5-5-6-8-10-12-14-16-18-20-25

102×4.5-5-6-8-10-12-14-16-18-22-25-30

108×4.5-5-6-8-10-12-14-16-18-20-22-25

114×4.5-5-6-8-10-12-14-16-18-22-25

121×4.5-5-6-8-10-12-14-16-18-20

127×4.5-5-6-8-10-12-14-16-18-20

133×4-5-6-8-10-12-14-16-18-20-22-25-28-30-32-35-40

140×6-8-10-12-14-16-18-20-22-25-28-30-32-35-40

152×6-8-10-12-14-16-18-20-22-25-28-30-32-35-40-50

159×4.5-5-6-8-10-12-14-16-18-20-22-25-30-35-38-40-45

168×5-6-8-10-12-14-16-18-20-22-25-28-30-35-38-40-45-50

180×5-6-8-10-12-14-16-18-20-22-25-28-30-32-35-38-40-45-50-55

194×6-8-10-12-14-16-18-20-22-25-28-30-32-35-38-40-42-45-50

203×6-8-10-12-14-16-18-20-22-25-28-30-32-35-38-40-42-45-50-55-60

219×6-7-8-10-12-14-16-18-20-22-25-28-30-32-35-38-40-45-50-55-60

232×14-16-18-20-22-25-28-30-32-35-38-40-42-45-50-55-60

245×8-10-12-14-16-18-20-22-25-28-30-32-35-38-40-42-45-50-55-60

273×6-8-10-12-14-16-18-20-22-25-28-30-32-35-38-40-42-45-50-55-60

299×8-10-12-14-16-18-20-22-25-28-30-32-35-38-40-42-45-50-55-60-65-70-75

325×9-10-11-12-13-14-16-18-20-22-25-28-30-32-35-38-40-42-45-50-55-60-65-70-75-80

351×10-12-14-16-18-20-22-25-28-30-32-35-38-40-42-45-50-55-60-65-70-75

356×8-10-12-14-16-18-20-22-25-28-30-32-35-38-40-42-45-50-55-60-65-70-75-80

377×8-10-12-14-16-18-20-22-25-28-30-32-35-38-40-42-45-50-55-60-65-70-75-80

402×12-14-16-18-20-22-25-28-30-32-35-38-40-42-45-50-55-60-65-70-75-80

426×8-10-12-14-16-18-20-22-25-28-30-32-35-38-40-42-45-50-55-60-65-70-75-80

480×10-12-14-16-18-20-22-25-28-30-32-35-38-40-42-45-50-55-60-65-70-75-80

508×10-12-14-16-18-20-22-25-28-30-32-35-38-40-45-50-55-60-65-70

530×12-14-16-18-20-22-25-28-30-32-35-38-40-45-50-55-60-65-70

610×30-35-40-45-50-55-60-65-70-75-80

630×30-35-38-40-45-50-55-60-65-70-75-80
