Main Parameters:
Single Head Maximum Flow Rate: 1800L/h
Maximum discharge pressure: 12bar
Adjustable ratio 10:1, steady-state accuracy ±1%
The lift height of the suction can reach up to 3 meters of water column.
Maximum inlet pressure is 2 bar
The minimum temperature for the material is 40℃.
Key Features:
Hydraulic End
Mechanical diaphragm drive, without diaphragm guard on the material side, facilitating material flow
PVC, PVDF, 316SS, high viscosity, and paste materials for pump heads, suitable for a variety of materials.
Self-cleaning one-way valve structure
Drive end
Variable eccentric mechanism adjustment ensures smooth and gradual flow pulsation changes
Enhanced structural design, suitable for stringent operating environments
Wear-resistant ball bearings for enhanced stability in operation.
Oil Valley Lubrication, extended service life for driving components
Flow can be adjusted in both shutdown and operational states, with manual, electric, or variable frequency adjustment options.
Control Method
Local manual control, adjust with the manual adjustment knob, adjust stroke length
