36L High-Capacity Box Furnace
Model: KSF12-36 | Purpose: Sintering and Annealing for Samples of Larger Dimensions
Dimensions: L: 750mm x W: 640mm x H: 830mm
Features: Energy-saving, simple structure, easy to operate
The design offers a comfortable and smooth user experience. Our pursuit of perfection is evident in our meticulous attention to detail, from every焊缝 on the casing to the polishing of every edge and corner. We strive for excellence in every aspect!
Key Features:
1. The furnace chamber is constructed of high-purity alumina fiber, offering excellent thermal insulation properties.
2. Double-layered furnace shell and additional air-cooling unit ensure safe shell temperature.
3. Special heating elements exhibit superior resistance to chemical reactions between the furnace charge and the heating elements.
Product Specifications:
| Product Name: | 1200℃ Large Capacity Box Furnace (36 L) |
| Product Model: | KSF12-36 |
| Extremal Temperature: | 1200℃ |
| Operating Temperature: | ≤1150℃ |
| Rise Rate: | Suggestion: 10℃/min |
| Furnace chamber size: | 300mm×300mm×400mm |
| Furnace chamber volume: | 36L |
| Control Mode: | Intelligent PID 30-step temperature control with overcurrent protection, over-temperature, and unbalanced alarm. |
| Temperature Control Accuracy: | ±1℃ |
| Thermometric element: | K-Type Thermocouple |
| Heating Element: | Molybdenum iron-chromium aluminum alloy heating wire |
| Furnace Material: | High-purity alumina fiber |
| Dimensions: | L:750mm×W:640mm×H:830mm |
| After-Sales Service: | One-year warranty, lifetime maintenance |
| Standard Accessories: | 1 set of combustion boards, 1 pair of protective gloves, 1 tongs for crucibles, 2 alumina crucibles, 1 instruction manual. |
| Standard Accessories: | All kinds of crucibles, brick pads, etc. |
