HWZ Type Direct-Connected Mixed Flow Pump

1. Overview:

The HWZ model is a single-stage, single-suction, cantilever, direct-connected mixed flow pump. It has all the advantages of the HW pump, plus features such as better coaxiality, higher efficiency, greater convenience of use, and lighter weight.

2. Application Range:

The HWZ series pumps are suitable for conveying clean water and liquids with physical and chemical properties similar to water, up to a concentration of 5% pulp or liquids with a pH of 3~10 and fiber length less than 80mm, at temperatures not exceeding 80℃. They are widely used in factories, mines, agricultural irrigation and drainage, industrial wastewater, and urban water supply and drainage systems. Particularly suitable for places with limited space and high requirements for working environment.

3. Performance Range:

Flow rate: 150~900 m³/h; Head: 3~12 m

Import diameter 150~300mm          Matching power 4~30kw
