Main technical parameters

1. Equipment dimensions:L7000×W1500×H1850（mm）

2By size: 700 × 300

3. Operating height:850（mm）

4. Conveyor speed:0.2-2m/min(steplessly adjustable)

5. Conveyor motor power:N=1.1Kw

6. Air heating tube power:2.5KW×15root=37.5KW

7. Power of hot air circulation fan:2.2Kw

8. Peak power of equipment:about40.8 Kw

Adopting a double-layer insulation structure.

Note: Non standard customized products can be customized according to needs!
