European Standard I-Beam Theoretical Weight Specifications Table(IPE)
Available Materials:S235、S275、S355、S460Pending
Tolerance Execution Standard:EN10034:1993
Name Specs Model Grain Weight(KG)
European Standard I-Beam IPE80 80x46x3.8x5.2 Grain Weight6KG Material
European Standard I-Beam IPE100 100x55x4.1x5.7 Grain Weight8.1KG Material
European Standard I-Beam IPE120 120x64x4.4x6.3 Grain Weight10.4KG Material
European Standard I-Beam IPE140 140x73x4.7x6.9 Rice weight12.9KG Material
European Standard I-Beam IPE160 160x82x5x7.4 Grain Weight15.8KG Material
European Standard I-Beam IPE180 180x91x5.3x8 Grain Weight18.8KG Material
European standard I-beam IPE200 200x100x5.6x8.5 Grain Weight22.4KG Material
European Standard I-Beam IPE220 220x110x5.9x9.2 Grain Weight26.2KG Material
European Standard I-beam IPE240 240x120x3.2x9.8 Grain Weight30.7KG Material
European Standard I-Beam IPE270 270x135x6.6x10.2 Grain Weight36.1KG Material
European standard I-beam IPE300 300x150x7.1x10.7 Rice weight42.2KG Material
European Standard I-Beam IPE330 330x160x7.5x11.5 Grain Weight49.1KG Material
European Standard I-beam IPE360 360x170x8x12.7 Grain Weight57.1KG Material
European Standard I-Beam IPE400 400x180x8.6x13.5 Grain Weight66.3KG Material
European Standard I-Beam IPE450 450x190x9.4x14.6 Grain Weight77.6KG Material
European standard I-beam IPE500 500x200x10.2x16 Grain Weight90.7KG Material
European Standard I-Beam IPE550 550x210x11.1x17.2 Grain Weight106KG Material
European Standard I-Beam IPE600 600x220x12x19 Grain Weight122KG Material
European standard common I-beams and light I-beams have variable cross-sections near the flange at the web side.,Outer thin; HSection steelHW HM HN HEA HEB HEM The flanges of the equal I-beam are of equal cross-section.
