Hardware accessories packaging machine

The packaging machines for hardware items feature smooth feeding, stable operation, low noise, and do not damage the raw materials. They are easy to operate and adjust. The feeding counting is accurate, with no issues of missing, excess, or *material. They are equipped with precise counting control devices to ensure each bag is accurate, with a pass rate above 98%. The equipment system has manual switching and self-diagnosis functions. In case of a fault, it can automatically stop and alarm. The emergency stop button should be installed in an easily accessible location for employee convenience.

Product Features:

Dual-frequency controller, bag length set and cut instantly, no need for adjustment or empty running, one-step solution, saves time and film.

2. User-friendly interface with convenient and quick parameter settings.

3. Fault self-diagnosis feature, fault display is clear at a glance.

4. High-sensitivity photoelectric eye color mark digital input for sealing position, ensuring more precise sealing location.

5. Independent PID temperature control, suitable for various packaging materials.

6. Stop positioning feature, non-stick blade, no film waste.

7. The transmission system is simple, more reliable, and easier to maintain.

All controls are software-based, facilitating function adjustments and technical upgrades.

Application Scope:

Suitable for packaging items with regular shapes such as bars of soap, popsicles, ice cream bars, lollipops, instant noodles, towels, and wet wipes, including long, round, and square forms.

Technical Specifications:

Model No.: QD-250B

Film Width: Max. 250mm

Bagging Length: 60-190mm, 120-350mm

Bagging Width: 30-110mm

Product Height: Max. 40mm

Film Roll Diameter: Max. 250mm

Packaging Speed: 40-230 packs/minute

Power Specifications: 220V, 50/60Hz, 2.4KVA

Machine Dimensions: (L) 3770 x (W) 670 x (H) 1450

Machine Weight: 800 Kg
