Round Tea Bag Packaging Machine

Application Scope:

This unit is suitable for granular materials in products such as tea, coffee, food, and chemicals.

Features:

Circular bags can automatically complete bag making, measuring, cutting, sealing, cutting, counting, and can also be configured with printing batch number functions according to customer requirements.

Utilizing a state-of-the-art microcomputer controller, it drives stepper motors to control bag length, featuring stable performance, easy adjustment, and precise detection.

Packaging Materials:Tea filter papers, etc.

Technical Specifications:

Bagging Size: Width (W): 180 (mm) Length (L): 90 (mm)

Packing speed: 40-50 bags/min Measuring range: 2-3g

Power Supply: 220V/50Hz/1.6KW, Gas Supply: 0.4-0.7mpa

Air Consumption: >0.1 m³/min 整机 Weight: 400 kg

Dimensions: (Length x Width x Height) 760×860×1730mm
