All metal parts must be galvanized; protect the galvanized layer during operation.


2. Made from galvanized steel pipe, the needle tip must have a wall thickness of not less than 3mm, and the soldering length of the needle tip must be not less than 70mm.


3. Lightning rods should be installed vertically and securely. The allowable deviation in verticality is 3/1000.


4. Welding requirements: The welding should be done by lap welding, and the lap length must comply with the following specifications:


5. The flat steel is twice its width (and has at least three edges welded).


6. The round steel bar is 6 times its diameter.


7. When connecting round steel with flat steel, the length is 6 times the diameter of the round steel.


8. Lightning rods are typically made of round steel or steel pipes, with diameters not less than the following: ① Independent lightning rods usually use 19mm galvanized round steel. ② Roof-mounted lightning rods use 25mm galvanized steel pipes. ③ Lightning rods at the top of water towers use 25mm or 40mm galvanized steel pipes. ④ Lightning rods on chimney tops use 25mm galvanized round steel or 40mm galvanized steel pipes. Lightning rings are made of 12mm galvanized round steel or 100mm² galvanized flat steel, with a thickness of 4mm.


9. Round steel or welded steel pipes should be used, with diameters not less than the following: For needles less than 1m in length: round steel 12mm, steel pipe 20mm; for needles 1-2m in length: round steel 16mm, steel pipe 25mm; for needles at the top of chimneys: round steel 20mm, steel pipe 40mm.
