Primary Applications of Small Laboratory Ultra-Pure Water Systems:

Analytical Reagents and Pharmaceutical Preparation Diluent Water

Biological, electrochemical, and interface research water

Microorganisms, water for biological fermentation cultivation, biological laboratory use

* MedicalProcess Water

Total Organic Carbon (TOC), testing experiments, analytical water

High-Precision Optical Lens Washing Water

Cleaning water for various components in the microelectronics industry

Medical biochemical analyzers, analytical instruments for water

Biological, pathological, and toxicological experimental water

Environmental and environmental protection experimental analysis water

Varying grades of liquid chromatography, ion chromatography, salt spray testing, and meteorological chromatography water

High-Purity Laboratory Water for Polymer Experiments

Precision Plating Water

Associate colleges and universities with scientific research, industrial and mining enterprises, laboratory experimental water



※Mid Pure Eco-Friendly Brand 『Design Advantages』:

1. One-on-one professional service, free on-site site survey, considering placement area and access space, and free water quality testing of raw water.

2. Understand the customer's full-day water demand, peak water usage, water quality requirements, and the customer's production process and industry characteristics.

3. Professional team collaboration with design, combined with on-site inspections by dedicated service personnel, and one-stop water treatment solution services.

4. Intelligent design with precise control, high level of automation, each unit can achieve automatic forward-wash/reverse-wash/operation, interlock protection, alarm indication, 4-20mA data open, can be remotely transmitted to the DCS central control system, truly realizing unattended operation.

5. Segment testing according to process requirements, capable of measuring conductivity, resistivity, pH, ORP, temperature, flow rate, velocity, pressure, and other parameters. Ensure that the water in every process step meets quality standards, without contaminating the finished water downstream, and place emphasis on process control.

6. Design products suitable for customers based on the principle of balancing comprehensive input and operational costs.

※Pure Environmental Protection Brand 『Production Advantages』:

1. Core components are all imported, and we have established long-term cooperative relationships with many international brands such as American DOW, Hydranet, GE, Siemens, Rhone-Poulenc, Grundfos of Denmark, Rosemount, Nippon Sumitomo, and Schneider, ensuring reliable product quality.

2. Suppliers conduct product evaluations, eliminating suppliers with poor quality and service, and selecting the best to enter the qualified supplier system.

3. Strictly adhere to the quality management system; quality is paramount. Conduct inspections on incoming materials for appearance and performance, production process checks, and final product quality inspection.

4. Production personnel produce according to corresponding codes, with shift scheduling and team-based production, responsibility division, and a well-established performance evaluation system with strong traceability.

5. Pre-shipment trial operation inspection, electrical point operation test, to ensure delivery of qualified products to the customer.

※Pure Environmental Protection Brand 'After-Sales Advantages':

1. Professional installation and after-sales team offering one-on-one service, enhancing the timeliness of post-installation after-sales support and improving customer satisfaction.

2. Establish a post-installation after-sales service mechanism, conduct performance evaluations, set up a customer service department, a complaint hotline, and promptly address customer concerns.

3. Full guidance and training throughout the installation and debugging process, including theoretical training, hands-on machine operation training, and general troubleshooting training.

4. Establish customer electronic profiles, conduct monthly phone follow-ups, and promptly provide methods and suggestions for reducing equipment operation costs.

5. Multiple channels for after-sales feedback, nationwide after-sales maintenance services, quick response, rapid handling, 24/7 service.

6. We solemnly promise: two-year free warranty for the entire unit, lifetime free technical support.

Section 1: Recommended Production Process:

1. Grade 1 Reverse Osmosis (RO): Product water conductivity ≤ 10 μS/cm (25℃)

Water source with pressure → Activated Carbon Filtration → 10um Filtration → 5um Filtration → High-pressure Pump → Primary Reverse Osmosis RO → Pure Water Tank → Transfer Pump → Water Usage Point

Note: If the raw water pressure is unstable, it is recommended to add a raw water tank and a raw water booster pump.

The process can be equipped with an optional UV sterilization/Ozone sterilization unit.

2. First-stage reverse osmosis RO + second-stage mixed bed: product water resistivity ≥ 5 MΩ·cm (at 25℃)

Water source with pressure → Activated Carbon Filtration → 10um Filtration → 5um Filtration → High Pressure Pump → Primary Reverse Osmosis RO → Primary Polishing Mixed Bed → Secondary Polishing Mixed Bed → Precision Filter → Ultra-Pure Water Tank → Transfer Pump → Water Usage Point

Note: If the source water pressure is unstable, it is recommended to increase the source water tank and source water booster pump.

The process can be optionally equipped with UV sterilization or ozone sterilization units.

3. First-stage Reverse Osmosis RO + Triple Mixed-bed: Product Water Resistivity: 15-18 MΩ·cm (25℃)

Water Source with Pressure → Activated Carbon Filtration → 10um Filtration → 5um Filtration → High-Pressure Pump → Primary Reverse Osmosis (RO) → Primary Polishing Mixed Bed → Secondary Polishing Mixed Bed → Tertiary Polishing Mixed Bed → Fine Filter → Ultra-Pure Water Tank (Recommended with Nitrogen Protection) → Transfer Pump → Water Usage Point

Note: If the raw water pressure is unstable, it is recommended to increase the raw water tank and raw water booster pump.

The process can be optionally equipped with an ultraviolet sterilization/ozonization sterilization unit.

II. Core Process Introduction:

1. Reverse Osmosis (RO) System

Reverse osmosis membranes, also known as RO, are a high-tech membrane separation technology invented by Loeb and Sourirtajan of the University of California, Los Angeles in 1960. Their pore size is as small as nanometers (1 nanometer = 10^-9 meters). Under certain pressure, H2O molecules can pass through the RO membrane, while inorganic salts, heavy metal ions, organic matter, colloids, bacteria, viruses, and other impurities in the source water cannot pass through the RO membrane, strictly separating pure water that can pass through from concentrated water that cannot.

Principle: Osmosis is a physical phenomenon where water from two bodies of water with different salt concentrations, separated by a semi-permeable membrane, will pass through the membrane until the salt concentrations are equalized. However, this process takes a long time and is known as natural osmosis. If a pressure is applied to the side with higher salt concentration, it can stop the osmosis, and this pressure is called osmotic pressure. Increasing the pressure can cause water to渗透 in the opposite direction, leaving the salt behind. Therefore, the principle of reverse osmosis desalination is to apply a pressure greater than the natural osmotic pressure to saltwater (such as raw water), causing the water molecules to be pushed to the other side of the membrane, resulting in clean water. This process removes salt from the water, hence the principle of reverse osmosis desalination.

Reverse osmosis membranes utilize aromatic polyamide spiral wound composite membranes. The reverse osmosis system consists of composite membrane elements, high-pressure pumps, fiberglass pressure vessels, chemical cleaning equipment, supports, and an instrument control cabinet. Equipped with a local control panel, which houses various local instruments and control buttons. The reverse osmosis desalination unit is controlled by a PLC for automatic operation. It's fitted with flowmeters, pressure gauges, conductivity meters, and more.

2. Polished Mixed Bed System

Polished mixed bed is generally used at the end of ultra-pure water treatment systems, based on the principle of resin ion exchange. The container is filled with non-regeneration polishing mixed bed nuclear-grade ion exchange resin, with ion forms being H and OH. As a terminal desalination unit, it can elevate the resistivity of the feed water from the previous stage to the user's required level, and also has certain control capabilities over TOC and SiO2.

Polished mixed bed ion exchange requires specific feedwater, which must be the product water from an anion, cation, or mixed bed ion exchange system, or from a continuous EDI (Electrodeionization) salt removal system. Only under feedwater conditions that meet these requirements can the polished mixed bed ion exchange operate stably and long-term.

Section 3: GBT 6682-2008 Specifications for Laboratory用水

IV. Selected Classic Customer Cases:



Section 5: National Warranty and Service System

1. Professional installation and after-sales team offering one-on-one service, enhancing the timeliness of post-installation after-sales support and boosting customer satisfaction.

2. Establish a post-installation after-sales service system, conduct performance evaluations, set up a customer service department, a complaint hotline, and promptly address customer concerns.

3. Comprehensive guidance and training throughout the installation and debugging process, including theoretical training, hands-on machine operation training, and general troubleshooting training.

4. Establish customer electronic profiles and conduct monthly phone follow-ups, promptly providing methods and suggestions to reduce equipment operating costs.

5. Multiple channels for after-sales feedback, offering nationwide maintenance and service support, with quick response and fast handling, 24/7 service.

6. Strictly Commitment: Two-year free warranty for the entire unit, lifetime free technical support.

For more product information, please call our 24-hour hotline at 18550863818 or the national hotline at 0512-69390898.

We will provide you with detailed plans, drawings, and competitive quotes for your reference and selection!

※ Phone consultation, enjoy 10% off! Welcome to call!
