Main Applications: General chemical ingredients, cleaning water, salt spray testing, electroplating industry, surface treatment, painting industry, electro-phoresis paint industry, boiler water, electronic power industry water, cleaning water, cleaning machine配套water, battery (lead-acid, lithium, zinc-manganese) water, laboratory pure water, coating water, ink water, etc.



※Green Pure Environmental Protection Brand 『Design Advantages』:

1. One-on-one professional service, free on-site site survey, considering placement area and access space, and free water quality testing of the original water.

2. Understand the customer's total daily water demand, peak water usage, water quality requirements, and learn about the customer's production process and industry characteristics.

3. Professional team collaboration with design, combined with on-site inspections by individual service personnel, and one-stop water treatment solutions services.

4. Smart design with precise control and high degree of automation. Each unit can perform automatic forward/reverse wash/operation, interlock protection, alarm indication, 4-20mA data openness, and can be remotely transmitted to the DCS control system, truly achieving unattended operation.

5. Segmentally inspect according to process requirements, capable of measuring conductivity, resistivity, pH, ORP, temperature, flow rate, velocity, and pressure, ensuring that water meets quality standards at every process stage without contaminating the finished product water downstream. Emphasize process control.

6. Design products that balance comprehensive investment and operational costs, tailored to meet customer needs.

※Pure Environmental Protection Brand 『Production Advantages』:

1. Core components are all imported, and we have established long-term cooperative relationships with numerous international brands such as Dow, Hydros, GE, Siemens, Rhone-Poulenc, Grundfos, Rosemount, Nippon Paint, and Schneider, ensuring reliable product quality.

2. Suppliers conduct product assessments, eliminating substandard suppliers with poor quality and service, and selecting the best to be enrolled in the qualified supplier system.

3. Strictly adhere to the quality management system; quality is paramount. Conduct incoming material appearance and performance inspections, production process inspections, and final product quality checks.

4. Production staff produce according to assigned numbers, grouped and scheduled shifts, responsible division of labor, establish performance assessment and strong traceability.

5. Pre-shipment trial operation inspection and electrical point operation test to ensure delivery of qualified products to the customer.

※Midway Eco-Friendly Brand 『After-Sales Advantage』:

1. Professional installation and after-sales team providing one-on-one service, enhancing the timeliness of post-installation after-sales support and increasing customer satisfaction.

2. Establish a post-installation after-sales service system, conduct performance evaluations, set up a customer service department, a complaint hotline, and promptly address customer concerns.

3. Full guidance and training throughout the installation and debugging process, including theoretical training, hands-on machine operation training, and general troubleshooting training.

4. Establish customer electronic profiles, conduct monthly phone follow-ups, and promptly provide methods and suggestions for reducing equipment operating costs.

5. Multiple channels for after-sales feedback, providing nationwide after-sales maintenance services, quick response, rapid handling, 24/7 service.

6. We solemnly promise: two-year free warranty for the entire unit, lifetime free technical support.

For more product details, please call our 24-hour hotline at 18550863818 or the national hotline at 0512-69390898.

We will provide you with detailed plans, drawings, and competitive quotes for your reference and selection!

※ Phone consultation, enjoy 10% off! Welcome to call!


II. RO Reverse Osmosis Purified Water Core Technology Introduction

1. RO Overview:

Reverse osmosis membranes, also known as RO, are a high-tech membrane separation technology invented by Loeb of the University of California, Los Angeles and Sourirtajan in 1960. Their pore sizes are as small as nanometers (1 nanometer = 10^-9 meters). Under certain pressure, H2O molecules can pass through the RO membrane, while inorganic salts, heavy metal ions, organic matter, colloids, bacteria, viruses, and other impurities in the source water cannot pass through the RO membrane. This allows for a strict separation of pure water that can pass through and concentrated water that cannot.

2. RO Principle Introduction:

Osmosis is a physical phenomenon where water from two bodies of water with different salt concentrations, separated by a semi-permeable membrane, will pass through the membrane until the salt concentrations are equalized. However, this process takes a long time and is known as natural osmosis. But if pressure is applied to the side with higher salt concentration, the osmosis can be stopped, and this pressure is called osmotic pressure. If the pressure is increased further, water can渗透 in the opposite direction, leaving the salt behind. Therefore, the principle of reverse osmosis desalination is to apply a pressure greater than the natural osmotic pressure to saltwater (such as raw water), causing the osmosis to occur in the opposite direction, pushing the water molecules to the other side of the membrane, resulting in clean water. This process removes salt from the water, achieving the goal of desalination.

3. Reverse Osmosis System Operation Diagram



4. Reverse Osmosis Auxiliary Components

The reverse osmosis membrane utilizes an aromatic polyamide spiral wound composite membrane. The reverse osmosis unit consists of composite membrane elements, high-pressure pumps, fiberglass pressure vessels, chemical cleaning equipment, supports, and an instrument control cabinet. Equipped with a local control panel, which is fitted with various local instruments and control buttons. The reverse osmosis desalination unit is controlled by a PLC for automatic operation. It is also equipped with flowmeters, pressure gauges, conductivity meters, and more.




V. Selected Classic Customer Cases:

Section 6: National Warranty and Service Network

1. Professional installation and after-sales team offering one-on-one service, enhancing the timeliness of post-installation after-sales support and boosting customer satisfaction.

2. Establish a post-installation after-sales service system, conduct performance evaluations, set up a customer service department, a complaint hotline, and promptly address customer needs.

3. Full guidance and training throughout the installation and debugging process, including theoretical training, hands-on machine operation training, and general troubleshooting training.

4. Establish customer electronic profiles, conduct monthly phone follow-ups, and promptly provide methods and suggestions for reducing equipment operation costs.

5. Multiple channels for after-sales feedback, providing nationwide after-sales maintenance services, quick response, rapid handling, 24/7 service.

6. We solemnly promise: Two-year free warranty for the entire unit, lifetime free technical support.

For more product details, please call our 24-hour hotline: 18550863818; or the national hotline: 0512-69390898.

We will provide you with detailed plans, drawings, and competitive quotes for your reference and selection!

※ Phone consultation, enjoy 10% off, welcome to call!
