Overview

YX1903BIs a three-channel single-line transmissionLEDDrive Control Chip

Utilize unipolar return-to-zero (RZ) data protocol.

YX1903BInternally, it includes a power clamp module, a signal decoding module,

Oscillator module, data regeneration module, output current drive module, etc. Among them

The data regeneration module automatically cascades the input data from this chip after receiving it.

Ensure data shaping and forwarding to maintain data integrity without attenuation during transmission.

YX1903BNo external resistor required.OUT R/G/BPort default output voltage

Flow17mAThe chip's peripheral components are few, simple, and reliable.

Features

Built-in power clamp, supports input power voltage5~24V

OUT R/G/B Default Constant Current Value17mA

OUT R/G/B Power-on Default State: Bright White Light

OUT R/G/B Port pressure resistance26V

OUT R/G/B Output Gray Scale Level:256 Grade

Data refresh synchronized across the same frame

Single-polarity zero-code data protocol adopted

Cascading data reshaped for output, to prevent data attenuation

Signal Transmission Rate:800Kbps

Packaging Style:SOP8
