ATOS proportional overflow valve, ATOS servo proportional valve, and detailed introduction of RZGO-TER-033/100

I. Overview of ATOS Proportional Spill Valve

The ATOS Proportional Relief Valve is a high-performance hydraulic control component produced by the Italian company ATOS. As a pioneer in electro-hydraulic proportional technology, ATOS provides a range of advanced electro-hydraulic proportional control products and technologies to customers worldwide. The ATOS Proportional Relief Valve plays a crucial role in hydraulic systems, allowing proportional adjustment of system pressure based on input signals, ensuring system stability and safety.

Working Principle

The working principle of the ATOS proportional overflow valve is based on fluid mechanics principles. It adjusts the flow velocity and the kinetic energy of the fluid by changing the throttle element (i.e., throttle area) whose local resistance may vary. This results in other pressure losses to achieve the purpose of pressure reduction. When the system pressure exceeds the set value, the overflow valve opens, allowing excess hydraulic oil to return to the reservoir, thereby maintaining system pressure stability.

2. Features

• High precisionThe ATOS proportional overflow valve employs advanced proportional control technology, enabling high-precision pressure regulation.

• Good stabilityThe valve core and seat have high mating precision and excellent sealing performance, ensuring the system's stability during long-term operation.

• Fast response timeProportional electromagnets can quickly respond to changes in input signals, thereby enabling rapid adjustment of the system's pressure.

• Easy to maintainThe structure is designed for easy disassembly and cleaning, reducing maintenance costs.

3. Application Fields

The ATOS proportional overflow valve is widely used in various hydraulic systems, such as injection molding machines, die casting machines, forging presses, and other mechanical equipment, as well as in hydraulic control systems for ships and aerospace fields.

Section 2: Overview of ATOS Servo Proportional Valve

The ATOS Servo Proportional Valve is another high-performance hydraulic control component from ATOS. It combines the advantages of servo and proportional control technologies, achieving high-precision and rapid response control of hydraulic systems.

1. Working Principle

The working principle of the ATOS servo proportional valve is based on electromagnetic control technology. By controlling the magnitude and direction of the electromagnetic current, the position and opening of the valve core are altered, thereby controlling the flow, pressure, and direction of the hydraulic system. Servo proportional valves typically use a closed-loop control system, which monitors the position of the valve core and the system status in real-time through feedback sensors and adjusts the electromagnetic current as needed to ensure system stability and accuracy.

2. Features

• High precisionServo proportional valves can achieve high-precision flow, pressure, and position control, meeting various complex control requirements.

• High response speedServo technology allows the valve core to quickly respond to changes in input signals, enhancing the system's response speed.

• Good stabilityClosed-loop control systems can monitor and adjust the system's status in real-time, ensuring stability and accuracy.

• High ReliabilityThe ATOS servo proportional valve is made with high-quality materials and advanced manufacturing techniques, ensuring the product's reliability and durability.

3. Application Fields

The ATOS servo proportional valve is widely used in various hydraulic control systems requiring high precision and rapid response, such as CNC machine tools, robots, and automated production lines.

Section 3: Detailed Description of RZGO-TER-033/100 Atos Solenoid Valve

The RZGO-TER-033/100 is a high-performance solenoid valve produced by ATOS, which combines the benefits of proportional control technology and solenoid valves to achieve control over the flow, pressure, and direction of hydraulic systems.

Product Features

• Tightly structuredThe RZGO-TER-033/100 solenoid valve features a compact structural design, reducing installation space and enhancing system integration.

• High precisionUtilizes advanced proportional control technology to achieve high-precision flow, pressure, and position control.

• High reliabilityThe solenoid valve is made with high-quality materials and advanced manufacturing techniques, ensuring the product's reliability and durability.

• Easy to maintainThe structure is designed for easy disassembly and cleaning, reducing maintenance costs.

2. Working Principle

The RZGO-TER-033/100 solenoid valve operates on the principle of solenoid control technology. When the solenoid is energized, it generates a magnetic field that attracts the valve core, thereby adjusting the valve opening to control the flow, pressure, and direction of the hydraulic system. Solenoid valves typically use open-loop or closed-loop control systems, selecting the appropriate control method based on the control requirements.

3. Performance Parameters

The main performance parameters of the RZGO-TER-033/100 solenoid valve include working pressure, flow rate, response time, etc. Specific parameters may vary depending on the model and specification of the product. Users can select the appropriate product based on their actual needs.

4. Application Fields

The RZGO-TER-033/100 solenoid valve is widely used in various hydraulic systems, such as injection molding machines, die casting machines, forging presses, and other machinery and equipment, as well as in hydraulic control systems for vessels and aerospace fields. It can also be combined with other hydraulic components to form complex hydraulic control systems, meeting various intricate control requirements.

5. Maintenance and care

To ensure the long-term stable operation of the RZGO-TER-033/100 solenoid valve, users must perform regular maintenance and care. Specific measures include:

• Regularly inspect the wiring and connections of the solenoid valve for looseness or damage, and replace or repair as needed.

• Regularly clean the oil污 and impurities inside the solenoid valve to maintain the cleanliness and smoothness of the valve core and seat.

• Regularly inspect the sealing performance of the solenoid valve to ensure it's good; replace the seals promptly if any leakage is detected.

• Regular performance testing and calibration of the solenoid valves are conducted to ensure their proper and accurate operation.

In summary, the ATOS proportional overflow valve, ATOS servo proportional valve, and RZGO-TER-033/100 ATOS solenoid valve are all high-performance hydraulic control components, playing a crucial role in various application fields. Users can select the appropriate products based on their actual needs and choose the right models by considering the product features and performance parameters. Additionally, regular maintenance and care of hydraulic components are essential for ensuring their long-term stable operation.
