The higher the arch height f of the floating trash interception device along the river channel, the greater the traction force T0; conversely, the higher the arch height f, the smaller the traction force T0. Therefore, selecting a reasonable arch height is crucial. An excessively high arch height may reduce the main traction force, simplifying design challenges, but it can affect the guidance of floating debris, causing pollutants to accumulate in front of the interception barrier. Conversely, an overly low arch height may improve the guidance of floating debris but increase design complexity and engineering investment, making it less economical. According to experience, the general range for arch height is between 1/8L and 1/12L, and the final determination is made based on the nature of the pollutants and the requirements for guiding floating debris.

Waterproof Floating Fencing Buoys; The wire rope clips commonly used for floating trash barriers are divided into three types: U-shaped, saddle-shaped, and embracing types. Among them, the saddle-shaped clip has strong connection force and is widely used. Generally, the rope clip model, type, and required quantity should be reasonably selected according to the diameter of the wire rope. When using, pay attention to:

When selecting rope clamps, the inner distance of the U-bolt should be about 1~3mm larger than the wire rope diameter. An excessive inner distance can cause the buckle to not securely clamp the wire rope, leading to slippage and potential accidents.

2. The bolts on the clips should be tightened until the wire rope is flattened to the diameter.

3. The U-section should contact the rope end, not be reversed with the main rope; rope clamps should be installed in a single line and evenly spaced.

4. To facilitate the inspection of whether the rope clamp joint is securely installed or to promptly detect any slippage at the wire rope joint, it is generally advisable to add an additional rope clamp approximately 500mm behind the next one and leave the wire rope end with a "secure bend." If the wire rope joint slips, the "secure bend" will visibly straighten, at which point immediate corrective action should be taken.
