Product Overview:

WAW-2000E Servo Hydraulic Test MachineUtilizing a double-space structure with the oil cylinder positioned below, the upper and middle beams form the stretching space, primarily for tensile testing of the sample. The worktable and middle beam create the compression space, enabling compression, bending, and shearing tests on the sample. Both the stretching and compression spaces can be automatically adjusted by rotating the lead screw to move the middle beam up and down.

WAW-2000E Servo HydraulicTesting MachinePrimarily used for tensile, compressive, bending, and shearing tests on metallic materials, equipped with corresponding fixtures, it can also be used for tensile, compressive, bending, shearing, and flexural tests on other types of specimens.

A closed-loop servo control system composed of a controller, servo valve, load sensor, displacement sensor, extensometer, and computer can automatically and precisely control the testing process and automatically measure test parameters such as force, displacement, and deformation.

The testing machine can perform tests with constant rate of force, deformation, and displacement, and can achieve three-segment control of force, deformation, and displacement in a single test, with smooth transitions between each control.

Test parameters are collected and processed by computer, enabling automatic control of the testing process and automatic calculation of test results. The computer screen displays the test curve and results in real-time, and test reports and curves can be printed.
