WNS Series Fuel (Gas) Steam Boiler Product Introduction

Quick-installation, three-pass, fire-tube steam boiler with inclined furnace tube and wet-back structure. High-temperature flue gases sequentially pass through the second and third pass smoke tubes, then through the rear smoke chamber and up the chimney. The boiler features movable front and rear smoke box covers for easy maintenance. Equipped with a technically advanced unit, it incorporates automatic proportional control, automatic water regulation, programmed start/stop, and fully automatic operation. It also boasts automatic protection functions such as high and low water level alarms, extremely low water level, over-pressure, and shutdown protection. This model is characterized by its compact structure, reliability, ease of operation, speed, low pollution, low noise, and high efficiency.

Key Features:

1. The overall structure of this gas-fired steam boiler is rational, compact, and belongs to the boiler island type, meeting the requirements for quick assembly and factory shipment. The product is composed of three main parts upon leaving the factory: the boiler main unit, chimney, and piping. The main unit and chimney sections are already completed within the factory, and the piping valves and instruments supplied with the main unit are pre-installed. Upon arrival at the site, simply connect the main unit and chimney, and the boiler can be tested by connecting the gas, power, and water supply lines. This significantly reduces the cycle time and ensures the quality of the product.

2. The boiler design features advanced performance. The main boiler body is an integrated structure, with the assembly located on the front smoke box cover, primarily arranged for the heating surface and chamber sections. It boasts a reasonable and compact structure, low steel consumption, and employs an offset corrugated furnace shell. The insulation layer is made of a new type of lightweight insulating material, the outer packaging is in colored thin plate, and the shape of the outer packaging is rectangular.

The boiler boasts superior performance, weight, structural dimensions, and aesthetic design compared to domestically produced counterparts of the same capacity. The water supply equipment is configured on the boiler base on the right side of the boiler, integrating it with the main unit and eliminating the need for an additional foundation.

3. The water cycle is simple, and the pressure component structure is reasonable. It can operate while ensuring water quality.

4. Comprehensive auxiliary equipment available, with advanced overall technical performance

2-ton gas boiler, 2-ton gas boiler manufacturer, 2-ton gas boiler model

2-ton gas steam boiler

Rated Evaporation Capacity: 2t/h       Rated Steam Pressure: 1.25MPa        Rated Steam Temperature: 194℃

Huzhou Boiler FactoryWe specialize in manufacturing WNS series gas-fired steam boilers, gas-fired pressure hot water boilers, and gas-fired atmospheric hot water boilers. Our technology is mature, and our products are safe and reliable. The boilers are equipped with advanced automation systems.PLCElectrical control cabinets, automatically adjusting the boiler's operating status, ensuring the boiler operates efficiently and stably within an optimized load range from high to low. Operation is more effective. The boiler's automated control electrical cabinet facilitates centralized management. Equipped with a world-renowned brand's highly efficient combustion burner, flue gas is fully combusted in the spacious furnace, reducing harmful emissions. Lower furnace heat load results in reduced NOx emissions, promoting clean and environmentally friendly operation.

He CookBoilers, WNS series oil (gas) fired steam boiler series, an innovative and energy-efficient product developed by integrating the advantages of European "Laursen" and "Viessmann" horizontal wet-back three-pass fire-tube boilers.

This product is equipped with world-renowned burners, known for their high level of automation, environmental friendliness, energy efficiency, and high performance, making them highly favored by customers. The company consistently adheres to the policy of "technology innovation and quality," placing great importance on the introduction of new technologies and the development of new products.

Heze Boiler Factory Co., Ltd.Welcome to visit our factory!
