Our company specializes in tank-type pressure vessels, which are among our key products. These include LPG storage tanks, liquid ammonia tanks, liquid chlorine tanks, propane tanks, pentane storage tanks, and low-temperature storage tanks for liquid oxygen and nitrogen. Particularly, our LPG storage tanks have reached mass production levels with a continuous production line, and various models are available in stock.

Table of Performance Parameters for Class III Storage Tanks

Tank Type Model Volume Effective m3 Working Pressure MPa Dimensions mm

LPG Storage Tank

[On the ground]

WG 1.77-1400-551.77DN1400×2750

WG 1.77-1400-10101.77DN1400×5980

WG 1.77-1600-10101.77DN1600×4400

WG 1.77-2000-20201.77DN2000×5650

WG 1.77-2200-25251.77DN2200×5800

WG 1.77-2200-30301.77DN2200×7100

WG 1.77-2600-40401.77DN2600×6600

WG 1.77-2600-50(B)501.77DN2600×8500

WG 1.77-2600-60601.77DN2600×10360

WG 1.77-3000-1001001.77DN3000×13200

WG 1.77-3600-1201201.77DN3600×10500

WG 1.77-3600-1501501.77DN3600×13500

WG 1.77-3800-2002001.77DN3800×16300

LPG Storage Tank

[Underground]

WDG 1.77-1400-551.77DN1400×2750

WDG 1.77-1600-10101.77DN1600×4400

WDG 1.77-2200-25251.77DN2200×5770

WDG 1.77-2200-30301.77DN2200×7100

WDG 1.77-2600-50501.77DN2600×8500

WDG 1.77-2800-60601.77DN2800×8740

WDG 1.77-3000-1001001.77DN3000×13200

Supply listed company He Guo brand LPG Storage Tanks, ranging from 5 cubic meters to 200 cubic meters of LPG storage tanks

专业定制液化气储罐哪家质量好-知名液化气储罐价格-销售液化气储罐批发价-正规液化气储罐制造厂

Attachment: Safety valves and pressure gauges must be rigorously inspected. It is essential to report for inspection to the local Quality Supervision and Inspection Bureau. This ensures better use by the customers. If the pressure gauge fails, the amount of gas consumption by your terminal at any given time would be unknown, and you would not be able to use it safely, fearing issues with the liquefied gas storage tank. Both the air compressor and the storage tank itself have safety valves. When pressure exceeds the safe set range of the safety valve, it will automatically release pressure. The pressure gauge also plays a significant role. Therefore, all daily accessories of special equipment should be used with caution. In case of any issues, first confirm if the steel plate thickness of the storage tank meets standards. If not, determine the cause of the steel plate corrosion. Also, reconfirm if the safety valves, pressure gauges, and other auxiliary equipment meet the requirements. If all are found to be non-compliant, the local Technical Supervision Bureau of the enterprise issues a notice of non-compliance. Upon receiving the notice, the enterprise is required to replace the new pressure vessel.
