Hekou Group 60 cubic meter LNG tank price

60-cubic-meter LNG storage tank is a low-temperature insulated tank of vacuum powder insulation type. It consists of a double container structure with an inner and outer container. The material used is Austenitic stainless steel, with the outer container material selected as Q235-B or 16MnR based on the user's location. The space between the inner and outer containers is filled with insulation material pumice and vacuumed. The insulation material is filled with pumice in a heated state and vacuumed.

60-cubic-meter LNG Storage Tank - Liquefied Natural Gas Storage Tank Application Range

Our products are suitable for industries such as steel, metallurgy, construction, chemicals, pharmaceuticals, food, glass, civil, and medical, and help reduce gas consumption costs. They are the preferred liquid gas storage containers across various industries.

Product Features of Liquefied Natural Gas Tanks

1. LNG Storage Tank Models: Vertical and Horizontal

2. Tank Effective Volume: 2m3-100m3 (common volumes include 2m3, 3m3, 5m3, 10m3, 15m3, 20m3, 30m3, 50m3, 100m3) and can be custom-designed to meet customer specifications.

3. Working Pressure: ≥0.2 MPa (common pressures include 0.8 MPa, 1.6 MPa)

4. Storage Media: Liquid Oxygen (LOX), Liquid Nitrogen (LIN), Liquid Argon (LAr), Liquid Carbon Dioxide (LCO2), Liquefied Natural Gas (LNG), etc.

5. Design Pressure: 0.84 Mpa, 1.68 Mpa; Working Pressure: 0.8 Mpa, 1.6 Mpa

High impact resistance and strong shock absorption.

60-cubic-meter LNG Storage Tank: Development of Liquefied Natural Gas Storage Tanks

With the development of the gas and natural gas industries, the application of liquefied natural gas (LNG) storage tanks has become increasingly widespread. In addition to large and extra-large horizontal low-temperature storage tanks for large LNG facilities and LNG receiving stations, air separation units, small and medium-sized LNG facilities, LNG storage and distribution stations, and LNG gasification stations typically use small and medium-sized horizontal low-temperature storage tanks, with capacities generally below 10,000 cubic meters. As the core equipment of these units, the choice of tank type significantly impacts the overall cost and operating expenses of the facility. Selecting the appropriate type of horizontal low-temperature storage tank to meet the installation requirements is therefore of utmost importance.

Liquefied Natural Gas (LNG) Storage Vessel Capacity and Applicable Scenarios

1. 60-cubic-meter LNG vacuum powder-insulated storage tanks, available in sizes from 5 to 200 cubic meters, suitable for civil gasification stations, industrial gasification stations, LNG refueling stations, small skid-mounted liquefaction units, and refrigerant storage.

2. Horizontal submersible low-temperature storage tanks, 300~5,000 cubic meters, suitable for small liquefaction units, air separation equipment, civil gasification stations, industrial gasification stations, and LNG gasification stations, etc.

3. Horizontal and Lateral Low-Temperature Storage Tanks, 100 to 10,000 cubic meters, suitable for small and medium-sized liquefaction units, peak-shaving liquefaction units, air separation units, LNG storage and distribution stations, LNG gasification stations, etc.

4. Vertical flat-bottomed cylindrical storage tanks, 200 to 200,000 cubic meters, suitable for various liquefaction units, LNG storage and distribution stations, LNG gasification stations, air separation units, liquid hydrocarbon storage, coastal LNG receiving terminals, etc.

Vacuum powder insulation storage tanks consist of an inner cylinder and an outer cylinder, with the annular space insulated using vacuum powder insulation technology. Due to transportation constraints, the maximum tank capacity is currently 200 m³, and they are commonly used for storing smaller quantities of liquid.

When the storage capacity exceeds 200m³, a 60-cubic-meter LNG storage tank can be connected in parallel as a cluster tank using multiple vacuum powder-insulated storage tanks. When the storage capacity exceeds 1500m³, it is advisable to use a mother-daughter horizontal low-temperature storage tank (shortened to mother-daughter tank), which has the advantages of fewer site equipment, lower investment, convenient operation and maintenance, and reliable safety compared to cluster tanks. The mother-daughter tank consists of multiple (over 3) daughter tanks in parallel to form the inner tank, and a large outer tank (mother tank) is assembled. The mother-daughter tank is also limited by transportation and lifting conditions, with a maximum individual capacity of 250m³ and a total maximum capacity of 5000m³. When the storage capacity exceeds 200m³, spherical horizontal low-temperature storage tanks and vertical flat-bottom cylindrical horizontal low-temperature storage tanks can also be chosen. When the storage capacity exceeds 10,000m³, horizontal low-temperature storage tanks with flat bottoms and vertical cylindrical shapes are more commonly used. During the actual selection process, when the storage capacity is less than or equal to 200m³, vacuum powder-insulated storage tanks with mature manufacturing and installation technology are chosen for the 60-cubic-meter LNG storage tank.

30立方LNG储罐厂家、30立方天然气储罐优质供应商

LNG储罐 在500m及以下容积时，30立方LNG储罐厂家球形低温储罐和立式平底圆筒形低温储罐的气相空间可容纳的BOG的量接近，在充装量及蒸发率相同的情况下，立式平底圆筒形低温储罐配备的BOG压缩机每开启1次，球形低温储罐配备的BOG压缩机分别需要开启1.02次、1.05次、1.06次，开启频率接近，运行费用相当。容积为10000m3时，30立方LNG储罐厂家立式平底圆筒形低温储罐BOG压缩机每开启1次，球形低温储罐BOG压缩机需开启2.42次，球形低温储罐运行费用高于立式平底圆筒形低温储罐。

LNG Tank Features:

(1) LNG Tanks - Our tanks excel in structural pressure resistance, load-bearing capacity, and insulation compared to vertical flat-bottomed cylindrical low-temperature storage tanks, with a 30 cubic meter capacity.

(2) For volumes of 1500m3 or less, the material cost of low-temperature liquid oxygen storage tanks is comparable or superior to vertical flat-bottomed cylindrical low-temperature storage tanks; for volumes greater than 1500m3, the material cost of vertical flat-bottomed cylindrical low-temperature storage tanks is more favorable than that of LNG tanks, with the advantage becoming more pronounced as the volume increases.

(3)建造难度方面低温液氧储罐略高于立式平底圆筒形低温储罐；建造周期二者相当30立方LNG储罐厂家。

(4) LNG tanks excel in terms of foundation footprint, cost, and safety compared to vertical flat-bottomed cylindrical low-temperature storage tanks.

(5) For storage capacities of 5,000 m3 or less, the operational costs of spherical low-temperature storage tanks are comparable to those of vertical flat-bottomed cylindrical low-temperature storage tanks; for capacities of 10,000 m3 or more, the operational costs of vertical flat-bottomed cylindrical tanks are lower than those of low-temperature liquid oxygen storage tanks. In general, when selecting low-temperature storage tanks of medium and small sizes, if the process requires pressurized storage, manufacturers of 30 cubic LNG storage tanks should opt for spherical low-temperature storage tanks; if pressurized storage is not required and the volume is between 200 m3 and 1,500 m3, low-temperature liquid oxygen storage tanks can be chosen; for volumes greater than 1,500 m3, vertical flat-bottomed cylindrical low-temperature storage tanks offer better economy.
