Fuel Gas Boiler Details
Huzhou Boiler FactoryCorporation forNationalRegional customers recommend oil-gas boilers, oil-gas boilers for factories, and atmospheric pressure boilers for factories.
CLHS/CWNS Fuel Gas Hot Water Boiler 1. Computerized Hot Water Boiler Controller, all functions are magically stored on a smart chip. One-button start for the boiler, with automatic timing and temperature control. Users can set the boiler's start and stop times. Once set, no need for constant supervision, saving time and effort.
2. Equipped with a dual-fuel burner that can operate on both oil and gas, featuring high automation. It automatically blows according to the controller's instructions, with electronic ignition and automatic combustion. The air-fuel (gas) ratio is automatically adjusted. The performance is safe and stable, and the combustion effect is excellent. It also includes an extinguishing protection device to ensure safe operation.
3. The fire tube is fitted with flame-retardant baffles, which slow down the smoke exhaust speed, enhance heat exchange, and result in lower smoke temperature exiting the smoke chamber. This reduces heat loss and saves fuel.
4. Large font display of water temperature for easy monitoring of boiler and system operation. Water temperature can be freely set from 10℃ to 90℃, and the boiler automatically heats the system or provides hot water for domestic use and bathing.
5. The control system regulates the start and stop of the circulating pump based on the boiler water temperature. For heating with a hot water boiler, the hot water circulating pump activates when the boiler water reaches the set upper temperature limit, and stops when it falls below the set lower temperature limit. For bathing with a hot water boiler, the hot water circulating pump stops when the boiler water reaches the set upper temperature limit, and starts when it falls below the set lower temperature limit.
6. The horizontal oil-gas fired hot water boiler features a three-pass full-wet back structure, utilizing a large furnace and large flue design to increase the radiant heat absorption of the furnace, effectively reducing energy consumption. The use of threaded flues and corrugated furnace tubes significantly enhances heat transfer, greatly reducing fuel consumption.
7. The unit is equipped with overheat protection (the burner automatically stops and beeps when the water temperature inside the furnace exceeds the high limit), secondary overheat protection (the secondary circuit is automatically cut off when the boiler shell temperature exceeds 105℃), dry burn and water shortage protection (the boiler stops working and beeps when the water level is below the extremely low level), and electric leakage protection (the power supply is automatically cut off when the control system detects electric leakage or short circuit).
8. Boilers are designed with an atmospheric pressure structure, operating in a non-pressurized state, posing no safety hazards.
9. Utilizing advanced centrifugal glass wool multi-layer insulation, with superior white color steel plate for exterior packaging, it boasts minimal heat loss and aesthetic rust resistance.
10. Fuel-gas hot water boilers are widely used in residential, villa, hospital, school, hotel, gym center, bath center, and other corporate and institutional settings.
Gas-fired steam boilerGas Boilers Natural Gas Boilers
Heze Boiler Factory Co., Ltd.
Control System UtilizedPLC ControlChinesePlease provide the Chinese content you would like translated into American English.The LCD screen serves as both a display and an operational platform, embedded with meticulously designed industrial control software and control circuitry. The system software not only meets general monitoring requirements such as manual/automatic control of gas boilers, condition monitoring, and real-time trends, but also includes additional features:Please provide the Chinese content to be translated.Recent years' meticulous analysis and research on boiler accidents have yielded a comprehensive system featuring fault detection, fault alerting, and fault handling, ensuring the maximum safety and reliability of boiler operations. Moreover, a standard RS-485 communication interface is provided for connection to computers, enabling remote monitoring or DCS integration. 13 kg pressure gas-fired steam boiler
Feature Overview:
Great convenience for the operator; the control system features both hardware manual control and software automatic control, along with functions for fault information processing, display, and inquiry. 13 kg pressure gas steam boiler
Manual Control
The system boasts robust artificial intelligence, interacting with boiler users through human-computer dialogue. In manual hardware mode, direct operation of various load devices is possible. In the event of general malfunctions, the display screen provides corresponding indications. For severe issues like water shortage inside the boiler, the display screen shows the faulty area, simultaneously automatically cutting off the burner's power supply, and issuing an audio alarm to alert the operator, ensuring the system operates safely.
