60m3Horizontal Low-Temperature Liquefied Natural Gas Storage Tank Technical Specifications
（2）Tank pipeline valve instrument list (Domestic high-quality products)
Serial Number | Name Please provide the Chinese content to be translated. | Specs | Quantity | Factory Home |
1 | Low Temperature Long Shaft Stop Valve | DN40 | 8Piece | Zhangjiagang Furu Special Equipment Co., Ltd. |
2 | Low-temperature long shaft stop valve | DN25 | 2Piece | Zhangjiagang Fortune Special Equipment Co., Ltd. |
3 | Low-temperature long shaft stop valve | DN10 | 1Piece | Zhangjiagang Furu Special Equipment Co., Ltd. |
4 | Needle valve | DN10 | 2Piece | Zhangjiagang Furu Special Equipment Co., Ltd. |
5 | Pipe safety valve | DN4 | 3piece | Zhangjiagang Furui Special Equipment Co., Ltd. |
6 | Three-way valve | DN25 | 1Piece | Zhangjiagang Furui Special Equipment Co., Ltd. |
7 | Safety valve | DN25 | 2Piece | Zhangjiagang Furu Special Equipment Co., Ltd. |
8 | Level differential pressure gauge | 15KPa | 1Set | Chengdu Lanshi, Sichuan |
9 | Vacuum Valve Assembly | DN30 | 1Set | Chengdu Lanshi, Sichuan |
10 | Oxygen Pressure Gauge | 0-1.6Mpa | 1Piece | Chengdu Tianwei |
Partial User Cases:
Huzhou Boiler Factory Co., Ltd. — Shandong Hekou Group
Liquefied Natural Gas (LNG) storage tanks, also known as LNG tanks, are specialized low-temperature liquid pressure vessels designed for the storage of liquefied natural gas.
Natural gas transitions from a gaseous to a liquid state and is referred to as liquefied natural gas (LNG) when cooled to -162°C under atmospheric pressure.
Liquefied natural gas (LNG) is colorless, odorless, non-toxic, and non-corrosive, primarily composed of methane, with a certain amount of ethane, propane, and heavier hydrocarbons.
Carbon and hydrogen compounds. Also, trace amounts of nitrogen, oxygen, carbon dioxide, and sulfur compounds.
Liquefied Natural Gas Storage Tanks are classified as type III pressure vessels, manufactured in accordance with the national GB150-98 standard for steel pressure vessels and GB18442-2001 standard for low-temperature containers, with on-site supervision and inspection by the National Technical Supervision authority.
The liquefied natural gas storage tank is a double-layered vacuum insulated low-temperature storage vessel, composed of the outer cylinder, inner body, insulation layer, thermal insulation material, root valve, level gauge, vacuum pump valve, and liquid inlet and outlet pipes.
The outer casing is made of 235B or 345R steel, while the inner casing is made of austenitic stainless steel.。
Product Specifications; 5-100 Cubic Units
