Project      Notes Explosion-proof Device     Top-mounted gravity explosion-proof device with constant opening pressure; explosion-proof door cover with double-sealing structure, providing tight sealing; easy to disassemble and reassemble the inspection door with low personnel requirements; large relief area for increased safety of the boiler; safe relief, hot gases emitted will not injure people. Front and Rear Smoke Boxes     The front and rear smoke boxes feature a double-sealing structure for tight sealing. Factory-leakage tested to ensure 100% no smoke leakage; smoke box welding is surface-inspected to prevent smoke leakage, condensation, and corrosion of the skin. Boiler Support     The support is fixed at one end and slides at the other, allowing the boiler to expand and contract freely during operation from cold to hot, eliminating拘束应力 for enhanced safety. Packaging and Insulation     Special insulation structure with excellent support for insulation effect. Insulation material uses refractory fiber from the largest manufacturer in Asia, "Luyang," resulting in lower skin temperature and reduced surface heat loss.

Performance Features

Design: Horizontal internal combustion three-pass full-wet back design, 100% corrugated furnace tube. Excellent thermal expansion properties. Integrated water enveloping fire design, ample heating surface area and reasonable structural arrangement, ensuring high-efficiency operation of the boiler.

Manufacturing Standards: The company has established a comprehensive quality assurance system that operates reliably, ensuring the entire manufacturing process is strictly controlled and supervised by a special inspection agency on-site.

High Efficiency & Energy Saving: Steam and hot water boiler series have thermal efficiencies ranging from 92% to 99.8%. The spacious combustion chamber combined with a rational structural arrangement transfers more heat into the water, significantly enhancing the heat exchange capabilities between fuel-steam and fuel-hot water.

Meets environmental protection standards: Large combustion space, fully utilizing radiant heat exchange, and equipped with high-quality and reliable imported burners, ensuring complete combustion of fuel and significantly reducing the emission of harmful components in flue gas. Our company's oil (gas) steam and hot water boilers have passed legal department testing and comply with national environmental protection standards, making them ideal eco-friendly products.

High heating quality: The steam boiler has ample steam storage capacity, ensuring high-quality dry steam under significant load fluctuations.

Superior Configuration: Equipped with world-renowned burners, an advanced control system (main components are imported), valves, and pumps are all selected from national top-quality products. The excellent boiler accessories configuration ensures a robust safety operation for the boiler.

Fully Automatic Operation: Simply press the start button, and the boiler will operate according to the set program. Load regulation, water supply, and other functions are all fully automatic, requiring no constant supervision.

Long service life: The professional design of boiler products, advanced production technology, and high-quality boiler-grade steel ensure that the normal lifespan of the boiler body is over 15 years.

Easy maintenance and repair: The boiler is equipped with movable ash box doors at both front and back, with observation and inspection holes at the rear for easy access to the furnace chamber for cleaning. Manholes are provided on the boiler body, with a structural design that takes into account ease of maintenance and repair in the future.

Attachment Configuration

Energy Saver: ND Steel Advantages

ND steel is currently the most ideal steel for "withstanding low-temperature dew point corrosion" both domestically and internationally. It is widely used in the manufacturing of devices and equipment such as economizers (energy savers), air preheaters, heat exchangers, and evaporators that operate in high-humidity flue gas environments to resist dew point corrosion caused by flue gas. ND steel also has the ability to withstand chloride ion corrosion. The main evaluation criteria for seamless steel tubes and plates made of 09CrCuSb (ND steel) are that the corrosion rate does not exceed 14mg/cm2·h after immersion in a 70°50% H2SO4 solution for 24 hours. Compared to carbon steel, Japanese-imported similar steel, stainless steel, and other corrosion-resistant capabilities, it is 1.84 times that of Japanese CR1R steel, 2.97 times that of 1Cr18Ni9 steel, 8.63 times that of Corten steel, and 14.11 times that of Q235B steel. ND steel's superior performance in withstanding dew point corrosion and its very high cost-performance ratio make it a completely suitable substitute for stainless steel and the best material to exceed stainless steel in terms of dew point corrosion resistance. ND steel holds significant economic value and aligns with the current "green" concept of high efficiency, long life, energy saving, and environmental protection, as well as the national development policy orientation. Comparison of 09CrCuSb steel (ND steel) with other steel grades

Steel Grades: 09CrCuSb (ND Steel), CRIR (Japan), 1Cr18Ni9, Corten, S-TEN (Japan), A3 (Q235B) Corrosion Rate: 7.30, 13.40, 21.70, 63.00, 27.4, 103.50 Multiples: 1, 1.84, 2.97, 8.63, 3.75, 14.11

Note: Corten steel, also known as Cor-Ten, is divided into two main categories: Corten A and Corten B. It represents the Cu-P series steel in the United States and is a low-alloy, high-strength atmospheric corrosion-resistant structural steel, referred to as weather-resistant steel in China.

Electrical Control System:

Stainless Steel Electric Control Cabinet DK Series, Automatic Water Filling, Low Water Alarm, Overload Alarm, Chain Protection, Nanjing "Zhengtai" Microcomputer Control

Heze Boilers  Gas Boilers  Natural Gas Boilers  Gas Steam Boilers

Product Introduction:

WNS fuel (gas) steam and hot water condensing boilers with external integrated finned tube economizers, independent condensers, compact structure, and easy maintenance, offer highly significant energy-saving effects. The thermal efficiency exceeds 100% based on the lower heating value of the fuel. To meet customer requirements, a combination of programmable logic controller (PLC) and a touch screen can be utilized, along with additional buttons, to achieve a dual-path intelligent control system for manual and automatic operation. Interfaces can be pre-installed for remote control capabilities.

The WNS series fully automatic fuel (gas) steam boilers (novel utility patent) feature a horizontal three-pass wet-back structure, improving the boiler's operating environment and enhancing efficiency and lifespan. All flue gas channels are submerged in water, equipped with a surplus hot water tank and a comprehensive insulation jacket design. The smoke box is sealed with a labyrinth structure, preventing any smoke leakage. The boiler achieves a thermal efficiency of over 85%, utilizing a combination of corrugated and conical furnace tubes with excellent expansion properties. The furnace tube size matches the flame, reducing the flue gas flow area sequentially, ensuring uniform flow of flue gas and maximizing heat exchange time in the furnace for better heat transfer. A high-performance burner perfectly matched with the boiler is used for full automatic regulation, ensuring complete combustion, fuel savings, and reduced pollution. Ultra-fine glass wool with high insulation properties is used to minimize heat loss. An intelligent energy-saving control system is employed to regulate the boiler and steam (water) supply systems, adjusting fuel supply based on different loads for greater energy efficiency. The installation is a complete quick-installation boiler, with minimal vibration and no special foundation requirements; it does not require anchor bolts, making installation simple and straightforward. The movable furnace head structure allows for compatibility with various burners, easy replacement of the furnace head, and quick maintenance of the furnace body. The front and rear smoke boxes are designed with removable, movable structures, enabling convenient internal inspection, maintenance, and care. The innovative product design, reasonable structure, and excellent process performance contribute to the superior quality of this product.

Product Features:

1. The design, manufacturing, and supervision inspection of the boiler strictly adhere to the "Regulations for Safe Supervision of Steam Boilers," JB/T 10094-2002 "General Technical Conditions for Industrial Boilers," and JB/T 1619-2002 "Technical Conditions for Shell-type Boiler Manufacturing," ensuring the long-term safe and stable operation of the boiler.

2. The body features a pot shell-type full-wet back downstream three-pass smoke tube structure. The flame burns at a slight positive pressure within the large combustion chamber, fully extending, resulting in low combustion heat load and minimal NOx emissions.

3. Wave-shaped furnace tube and threaded flue structure, which enhances strength while meeting the expansion requirements of each part.

4. All main welds are joined by butt welding and have been inspected by X-ray and ultrasonic non-destructive testing to ensure the welding quality meets national standards.

5. The boiler has a large water volume and gas space, with strong load adaptation capability. The design of the internal equipment is reasonable, ensuring the steam moisture content is less than 4%, meeting the higher quality requirements of steam from the user.

6. Utilizes advanced thermal insulation materials, lightweight, with minimal heat loss and excellent thermal retention properties.

7. The water level alarm uses stainless steel as the electrode rod and polytetrafluoroethylene as the insulating material. It can be inserted from above, is less prone to dirt, performs reliably, and has a long service life.

8. The front and rear cigarette boxes are hinged for easy opening, facilitating convenient and quick maintenance.

9. Oxygen Content Regulation (Optional): This system successfully monitors the oxygen content in flue gas and transmits the data in real-time to the control system. Through intelligent analysis by the computer, it automatically adjusts the proportion of the combustion equipment, keeping it in perfect working condition. This significantly improves combustion efficiency, thereby greatly reducing fuel consumption.

System Protection:

The boiler features multiple safety protections: electric leakage protection, which automatically cuts off power in case of leakage; overheat protection, which stops the burner and sounds an alarm when the boiler water temperature exceeds the alarm temperature; secondary overheat protection, which cuts off the secondary circuit and stops the boiler when the outer shell temperature exceeds 105℃; dry burning prevention protection, which uses a precision water level electrode rod to monitor the water level in real-time, stopping the boiler and preventing dry burning in case the water level reaches or falls below the critical level due to other reasons.

Application Fields:

Ironing, dry cleaning, drying, washing, spinning, pressing, and flat irons, etc., are all used in conjunction with each other.

2: Supply drinking water, steamed food, rice noodle production, soy milk boiling, tofu machine, steamed rice box, sterilization tank, labeling machine, filling machine

Matching sets of paint equipment, sealing machines, tableware cleaning, etc.

3: Room heating, centralized heating, underfloor heating, community centralized heating, auxiliary air conditioning (heat pump) heating, compatible with solar energy for hot water supply.

Hot water supply for hotels, dormitories, schools, and mixing stations; concrete curing for bridges and railways; sauna and bath services at leisure beauty clubs; wood flooring processing, etc.

4: Vehicle washing (e.g., cars, trains), shoe sole rubber molding, and painting industries.
