Fully Automatic High-Efficiency Energy-Saving Gas Steam Boiler

I. Principle of Boiler Operation:

    WNThe S series fuel (gas) steam boiler is a quick-installation internal combustion boiler, equipped with a high-performance fully automatic burner as the main combustion unit. It produces high-temperature flames through the automatic ignition function, which then exit the boiler through the upper smoke channel and are released into the atmosphere through the chimney. This type of boiler has a high heat exchange efficiency, a simple structure, and a long service life.

II. Characteristics of the Boiler Body:

1. Crafted from high-quality boiler steel plate, in compliance with the national JB/T10393 standard.

2. Utilizes a water-tube crossflow structure for high heat exchange efficiency and long service life.

3. Boilers' weld seams 100% X-ray inspected and accompanied by a certificate of compliance.

4. Utilizes high-quality, efficient thermal insulation materials with minimal heat loss.

Section 3: Features of Boiler Electrical Control System:

Pressure Limit Automatic Control Device

2. Automatic Safety Valve Discharge Unit

3. High/low water level, trigger an alarm and immediately stop heating.

4. Overcurrent shutdown and alarm

Principle of Operation for Gas Boilers:

Water in the pot (pot shell) is continuously heated by the energy released from the combustion of gas fuel in the furnace, causing the temperature to rise and produce pressurized steam. As the boiling point of water increases with pressure, the pot is sealed, and the expansion of the steam inside is restricted, creating pressure to form thermal power (to be precise, the steam in the boiler is formed by water heated to saturation in the pot shell at a constant pressure and then vaporized). As an energy source, it is widely used.
