Fully Automatic High-Efficiency Energy-Saving Gas Steam Boiler

Boiler Working Principle:

    WNThe S Series fuel (gas) steam boiler is a quick-assembled internal combustion boiler that utilizes a high-performance fully automatic burner as the main combustion equipment. It produces high-temperature flames through an automatic ignition function, which then exit the boiler through the upper smoke channel and are discharged into the atmosphere through the chimney. This model features high heat exchange efficiency, a simple structure, and a long service life.

Section 2: Features of the Boiler Body:

1. Made of high-quality boiler steel plate, in compliance with the national JB/T10393 standard.

2. Utilizes a pipeline through-flow structure, offering high heat exchange efficiency and a long service life.

3. Boilers' weld seams 100% X-ray inspected and accompanied by certification.

4. Utilizes high-quality and efficient thermal insulation materials with minimal heat loss.

III. Features of Boiler Electrical Control System:

Pressure Limit Automatic Control Device

2. Automatic Safety Valve Discharge Unit

3. High or low water level, trigger an alarm and immediately stop heating.

4. Overcurrent shutdown and alarm

Principle of Gas Boiler Operation:

Water in the kettle (drum) is continuously heated by the energy released from the combustion of gas fuel in the furnace, causing the temperature to rise and generating pressurized steam. As the boiling point of water increases with pressure, the kettle is sealed, and the expansion of steam inside is restricted, creating pressure to form thermal power (strictly speaking, the steam in the boiler is formed by water being heated to saturation at a constant pressure in the drum and then vaporizing). As an energy source, it is widely used.

I. Overview

This is a quick-installation horizontal internal combustion three-pass fire-tube boiler. It features an offset furnace tube semi-wet-back structure, where high-temperature flue gases sequentially wash the second and third pass flue tubes, and then are exhausted into the atmosphere through the rear smoke chamber and chimney. The boiler is equipped with removable front and rear smoke box lids for easy maintenance. The boiler is fitted with world-renowned burners and incorporates advanced technologies such as automatic proportional combustion adjustment, automatic water regulation, programmed start/stop, and automatic operation. It also features high and low water level alarms, as well as automatic protection functions for extremely low water levels, over-pressure, and extinguishing. This model boiler is characterized by its compact structure, safety, ease of operation, quick installation, low pollution, low noise, and high efficiency, and is widely applicable to industrial steam for enterprises, hotels, office buildings, residential buildings, and other facilities for both industrial and domestic heating and heating use.

Our company's developed Light Oil Boiler series utilizes internationally advanced automation technology with higher levels of automation.Italian ImportedThe fully automatic burner, as the main combustion equipment, is controlled by a more advanced combustion program controller, enabling all necessary functions for the normal combustion of fuel boilers. It can automatically implement protective shutdowns in normal, emergency, and extreme conditions. Equipped with a corresponding water level controller and pressure proportional regulator, it ensures low and high water level indication, overpressure indication, and adjustment, maintaining water levels within the normal range and steam pressure within the permissible fluctuation range. It also features a protective stop indication in cases of extremely low water levels or overpressure.

II. Key Features

The overall structure is rational and compact, belonging to the boiler island type, and meets the requirements for quick assembly and factory shipment. The product is composed of three main parts upon factory delivery: the boiler main unit, chimney, and piping system. The main unit and chimney sections are already manufactured on-site, and the accompanying piping valves and instruments are pre-installed. Upon arrival at the site, simply assemble the main unit and chimney. Once the gas, power, and water supply lines are connected, the unit can be tested. This significantly reduces the installation period while ensuring product quality.

2. Advanced design performance. The boiler's main body features an integrated structure, with the burner assembled on the front smoke box cover, and the main body primarily arranged with heating surfaces and combustion chambers. It boasts a reasonable and compact structure, low steel consumption, and uses an offset corrugated furnace drum. The insulation layer is made of a new lightweight thermal insulation material, and the outer packaging is made of colored thin plates. The shape is rectangular, making the boiler's performance, weight, structural dimensions, and appearance significantly more advanced and aesthetically pleasing compared to domestic products of the same capacity. The water supply equipment for the boiler is configured on the boiler's base on the right side, making it an integral part of the main body and eliminating the need for an additional foundation.

3. Simple water circulation, reasonable structure of pressure parts, can operate safely while ensuring water quality.

4. Comprehensive auxiliary machinery available, with advanced comprehensive technical performance.
