60CubicLNGTank Technical Parameters:

Container Type: IICategory   Structure Type: Horizontal   Insulation Method: Vacuum Powder Insulation (Pearlescent Sand)

Please provide the Chinese content you would like translated into American English.    Quality: LNG(Liquefied Natural Gas (LNG)      Maximum allowable working pressure:0.86Mpa

Design Temperature: Inner Shell:-196℃           Outer Shell:-20-50℃

Work Pressure:0.8Mpa  Outer Shell:-0.1 MPa Design Pressure:0.84Mpa Outer Shell:-0.1 MPa

Available    Accumulated:60m3   Effective Volume:54m3 Material: Inner Shell:S30408    Outer Shell:Q345R

Spec: Inner Liner:?2400×12400×7/8 Outer Shell:?2900×13140×8/10 Total Length:14929mm
  Total Weight:21760kg      Laminate Spacing:250mm       Inner tube material:S30408       Dimensions?2916×14929mm

Insulation Sandwich Material:TCHP-50Type Pearl Shine Sand    Fill Volume: >30.8m3

Internal bladder pressure test: Medium: Nitrogen         Test Pressure:1.06Mpa

Valves; Low-temperature stainless steel stop valves  Final vacuum degree: ≤5Pa    Static Evaporation Rate ≤0.316%/d

Vacuum Insulation Layer Air Leakage Rate ≤2×10-6 Pa.m3/s Vacuum Insulated Jacket Air Leak Rate ≤6×10-5 Pa.m3/s

Manufacturing Acceptance Standards:

GB/T18442.1~18442.6-2011, TSG21~2016"Regulation for Solid Content"NB/T47042-2014

60m3Horizontal Low-Temperature Liquefied Natural Gas Storage Tank Technical Specifications

（2）Tank pipeline valve instrument list (domestic high-quality products)
