This product is a horizontal fixed vacuum powder insulation low-temperature storage tank, featuring a double-layer cylindrical structure. The inner container is designed for storing low-temperature liquid natural gas, while the outer shell forms and protects the vacuum insulation space. The gap is filled with pearlescent sand and evacuated to create an effective insulation system. The design of the outer shell and support system can withstand the relevant external forces generated during manufacturing, transportation, installation, and use. The bottom of the tank is equipped with a complete set of valves, instruments, and safety devices for operation.

Safety:

One, stainless steel sheets are sourced from Taiyuan Iron and Steel Plant, the leading manufacturer of stainless steel sheets in China, ensuring quality. Pipe materials are purchased from Anhui Tian Da Steel Pipe, the number one supplier of domestic stainless steel seamless pipes.

    Two, materials are all in accordance withGB150-2011The "Pressure Vessel" undergoes re-inspection, with material cutting performed by a CNC plasma cutting machine, ensuring strict control over the geometric dimensions of the cylinder sections.

    Three: Both longitudinal and circumferential seams are welded using submerged arc welding, resulting in good appearance and molding, and the inner shell undergoes100%XRay inspection.

Vacuum Degree:

One, the inner and outer surfaces of the stainless steel liner are treated with degreasing and acid pickling passivation, while the carbon steel shell has undergone sandblasting and rust removal on both the inner and outer surfaces, ensuring the paint's adhesion, extending the paint's corrosion resistance lifespan, enhancing the stainless steel plate's corrosion resistance, and reducing the amount of air release from the sandwich, thereby guaranteeing the lifespan of the vacuum degree.

    2. Prior to loading sand, perform a unique dehydration pre-treatment on pearl sand, and heat the sandwich layer with nitrogen to replace the air, significantly reducing the source of gas release.

    Three, the process of negative pressure filling and positive pressure compaction for sand ensures the uniformity of the sandwiched pearlescent sand. The use of vibration rod compaction technology maximizes the filling amount of the pearlescent sand, guaranteeing the insulating effect of the sandwich.

    Four: Utilizing a unique vacuum extraction process, significantly reduces the vacuuming time for the inner shell and sandwich layers, ensuring the vacuum level of the sandwich exceeds national standards. Guarantees the vacuum level of the storage tank is3～5No reprocessing required within the year.

Appearance:

  One. Elbows are bent on a CNC bending machine, ensuring strict dimensional accuracy of the elbows. By not using elbow joints, pipe resistance is significantly reduced, and the aesthetic appearance of the external pipeline system is also improved.

    The paint used is from the world-renowned Jotun brand, with two coats of primer and two coats of topcoat applied, ensuring the paint's longevity and the quality of the equipment's appearance.

Low-temperature storage tanks are primarily used in the industrial gas sector, with a wide range of applications across various industries. These include steel mills, chemicals, oil, food, and aerospace, all of which require gases. Industrially, gases like oxygen, nitrogen, and argon, which are in high demand, are separated from air using air separation equipment. The air is compressed and liquefied, then separated based on the different boiling points of oxygen, nitrogen, and argon, before being stored in low-temperature storage vessels.

    Liquefied Natural Gas (LNG)The tank features a long service life, compact structure, minimal land occupation, centralized control, ease of operation and maintenance, and is a double-layer fixed vacuum powder insulation low-temperature storage tank. The inner shell is made of stainless steel.,Outer case material isQ235BOr16MnRThe liquid oxygen tank surface is coated with an anti-corrosion layer using processes such as sandblasting, sweeping, and spraying, while also utilizing a two-component quick-curing liquid paint.

Liquefied Natural Gas (LNG) storage tanks are composed of the tank body, instruments, pipelines, valves, etc. These storage tanks are equipped with two types of liquid inlet methods, upper and lower, which can be selected and used according to actual conditions.

The inner tank of the Liquefied Natural Gas (LNG) storage tank is equipped with a safety system device featuring dual safety valves. In normal operation, one set is in working condition while the other is on standby. If the working safety valve trips, the manual pressure relief valve is immediately opened to release pressure to the highest working pressure of the tank. Simultaneously, the safety device is quickly switched to the standby system via the manual handle, effectively ensuring the tank's safety. This safety system device consists of safety valves, explosion-proof devices, vent valves, and three-way ball valves, not only improving pipeline welding but also featuring excellent fire and static electricity prevention structures. Additionally, the safety relief openings on the casing are fully guaranteed to ensure the entire equipment's safety and reliability. The low-temperature pipelines are集中引出 for operation and control, and the outlet is designed with a Duralumin structure to meet low-temperature requirements and reduce stress caused by thermal expansion and contraction in the pipelines, ensuring the tank's safety. The vacuum pump valve is sealed with three "O" rings, effectively ensuring the reliability of the sandwich seal, and is made of full stainless steel with a compact size. A novel suspended structure is designed for the top of the LNG storage tank for easy transportation, lifting, and installation. A unique manhole design ensures the cleanliness inside the inner tank when it is sealed. Vacuum isolation valves and combined vacuum gauges are used on the LNG storage tank for measuring and maintaining the vacuum degree of the tank's sandwich, extending the tank's service life and enhancing its quality. The LNG storage tank is equipped with a level gauge and a pressure gauge for local display of liquid level and pressure.
