I. Product Overview

This series of pure water oxygen generators employs Solid Polymer Electrolyte (SPE) oxygen production technology, utilizing pure water as the electrolyte and generating high-purity oxygen through electrolysis with titanium metal electrodes. The oxygen is then separated from water, dried, and purified before being output, featuring core advantages such as stable pressure (fluctuations < 0.001 MPa), on-demand production, and zero addition of alkaline solution. It is suitable for laboratory, medical, and industrial applications.

ThreeInstrument Features

1. Smart Control System

One-touch operation: Simply press the power switch to start generating gas, supports continuous/intermittent operation.

Accurate Monitoring: Highlighted LED digital screens display flow (±1ml accuracy) and pressure values in real time, with data being clear and easy to read.

Pressure Adaptive: The system automatically adjusts the gas output when the pressure reaches the preset value (e.g., 0.4MPa), ensuring the output pressure fluctuation ≤0.001MPa.

2. Low-maintenance design

Simplified Maintenance: Simply replenish with pure water or distilled water as needed.

3. Safety Protection

Anti-backflow Technology: Equipped with an anti-backflow device, eliminating the risk of liquid backflow.

Multi-protection: Overvoltage and low-liquid automatic shutdown for equipment and operation safety.

4 High-Efficiency Compact Structure

High conversion efficiency: Electrolytic cell efficiency ≥95%, maximum gas production up to 500ml/min, meeting high load requirements.
